4. To remove the staple cartridge, and open the clamp, pull the clamp in the direction shown.
5. Remove the jammed staples, then push the clamp in the direction shown until the clamp clicks into the locked
position.
WWaarrnniinngg:: The points of the jammed staples are sharp. Remove the jammed staples carefully.
6. Grasp the staple cartridge handle, then insert the cartridge into the stapler until the cartridge clicks into
position.
328 Xerox
®
AltaLink
®
C8130/C8135/C8145/C8155/C8170 Series Color Multifunction Printer User Guide
Troubleshooting
