4. To open the staple cartridge clamp, pull the clamp in the direction shown.
5. Remove the jammed staples, then push the clamp in the direction shown until the clamp clicks into the locked
position.
WWaarrnniinngg:: The points of the jammed staples are sharp. Remove the jammed staples carefully.
6. Grasp the staple cartridge by the orange handle, then insert the cartridge into the stapler assembly until the
staple cartridge clicks into place.
7. Return the stapler assembly to the original position, then close the finisher door.
334
Xerox
®
AltaLink
®
C8130/C8135/C8145/C8155/C8170 Series Color Multifunction Printer User Guide
Troubleshooting

Xerox AltaLink C8130 Series Specifications

General

Maximum Paper Capacity	5, 140 sheets
Copy Resolution	Up to 600 x 600 dpi
Fax	Optional
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Automatic
Memory	4 GB
Type	Color Multifunction Printer
Fax Resolution	Up to 400 x 400 dpi
Display	10.1-inch color touchscreen
Print Speed	Up to 30 ppm
Connectivity	Ethernet, USB 3.0
Hard Drive	320 GB (optional)
Functions	Print, Copy, Scan, Fax (optional)
Copy Speed	Up to 30 cpm (black/white and color)
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria, Xerox Print Service Plug-in for Android
Dimensions	640 x 699 x 1, 147 mm
