DefinitionSymbol

Lock

Unlock

Do Not Touch

Do Not Dispose into an Open Flame / Incinerate

Paper Jam

Do Not Use Transparencies / Overhead Projector Sheets

Do Not Use Tabs

Do Not Use Media Attached with Staples or Paper / Metal Clips

Load Drilled Paper as Indicated

Load Labels as Indicated

Xerox

Nuvera

2-2

User Guide and Training Aid (UGTA)

Product Symbols
