Specifications
BFM PlusBFM
Only available on the Bypass BFM
Top Tray with Direct Connect
250 sheets of 20 lb bond (76 gsm)
or equivalent
Output to the Top Tray is delivered
with Side-1 down and sets are not
offset. It can be set as a destination
tray for non-stapled jobs. Sheets less
than 7 inches in the process direction
or 8 inches in the cross-process direc-
tion will automatically go to the Top
Tray. The Top Tray also receives
sheets that are purged from the sys-
tem.
Top Tray Capacity
Same3000 sheets of 20 lb bond (76 gsm)
or equivalent
The stack limit can be set from the
UI for each BFM independently.
Stapled sets with <15 sheets are lim-
ited to 100 sets.
The Stacker is the output tray for re-
ceiving compiled stapled and un-
stapled sets as well as single sheets.
Output is normally delivered with
side-1 down and sets can be offset.
Stacker Capacity
SameUp to 100 sheets of 20 lb bond (75
gsm) (one or two staples) or equival-
ent substrates(reducedstapledsheet
capabilities can result based on sub-
strate properties (i. e. thickness,
density, material, coating, etc.)
Includes two internal pass-through
100 sheet upside down staplers. The
stapler devices have the ability to
portrait, landscape or dual staple all
supported paper sizes. Finished sets
can be stacked internally to the lower
stacker tray.
If either of the Staplers runs out of
staples see Replacing Staples or if it
jams see Clearing Staple Jams.
An alternate Staple Cartridge for up
to 30 sheets of 20lb is available. (75-
80 gsm) paper capacity. Contact
Xerox for information on ordering
refills.
Each Stapler Cartridge holds 5000
staples. Contact Xerox for informa-
tion on ordering refills.
Stapler Capacity
21-19Xerox
®
Nuvera
®
User Guide and Training Aid (UGTA)
Machine Specifications
