BFM PlusBFM
Same8.26 in to 18.5 in (210 mm to 457
mm)
8.0 in to 12 in (200 mm to 305 mm)
Paper Size Range
process direction
cross process direction
Same16 lb bond to 113 lb index (52 to 300
gsm)
90 to 300 gsm
Stock Weight Range
uncoated:
coated:
Note
For information on how to use the BFM and BFM Plus and send documents to the stacker, see Using
the Basic Finishing Module (BFM) and Delivering Document Sets to the Stacker.
Configurations
There are a number of possible Feeder and Finishing combinations when installing the Sheet Feed
Modules, the Insertion Modules, the BFM, XPS and other external finishers on a Xerox Nuvera system.
Note
For increased productivity, the system can support up to four SFM feeders, up to two Insertion Modules,
and up to three XPS Modules. The BFM and BFM Plus or BFM Plus and BFM Plus can be installed together
to double the stacker capacity.
Configuration examples for the 100/120/144 and 200/288 system include:
The diagrams below highlight some of the more common finishing configuration options. Only the
Nuvera EA Production System with a MFF does not include a Sheet Enhancement Module, which is
always located directly after the print engine (or second print engine on the 200/288/314 system).
Figure 28: Print Engine / Sheet Enhancement Module / BFM
Figure 29: Print Engine / Sheet Enhancement Module / Insertion Module / BFM
Xerox
®
Nuvera
®
21-20
User Guide and Training Aid (UGTA)
Machine Specifications
