Usage RecommendationPaper Type
A system with a MFF supports:
• 52 gsm - 220 gsm uncoated stock; coated not supported
The weight range supported on a system with a DS3500/XPS depends on
the 3rd party device, but most are 52 gsm - 300 gsm for uncoated stock
and 90 gsm - 300 gsm for coated stock.
If you are loading any type of drilled paper, to aid in sheet separation and
to prevent jams, it may be helpful to fan reams before loading into the tray.
Drilled stocks
Loading limit in Paper Feeder trays: 50 sheets.Transparency or Mylar reinforced
sheets
Loading limit in Paper Feeder trays: 50 sheets.
Load with stripe down on the lead edge.
Note
For dedicated transparency trays, first place approximately half an inch (12
mm) worth of plain paper at the bottom of the tray. This will ensure that
all 50 of the transparencies get used.
Removable stripe transparencies
Label Stock
• LEF
• Loading limit in Paper Feeder trays: 50 sheets.
Carbonless Forms
• LEF
• For 1 to N printing order, load with top (white) sheet on top
• For N to 1 printing order, load with top (white) sheet at the bottom
Booklet Envelope (closed flap)
• 6"x9"
• 9"x12"
• 162x229
• 220x312
• Types: Closed flap, flap on long edge.
• Loading orientation: Address side up and flap-side leading
• Output to MFF top tray only
• Loading capacity limit - 60
• Output to top tray limit - 15** **More than 15 envelopes can be output
to the tray, as long as the tray is tended and emptied every 10-15 envel-
opes.
Catalog Envelope (open flap)
• 6"x9"
• 7"x10"
• 162x229
• 178x254
21-5Xerox
®
Nuvera
®
User Guide and Training Aid (UGTA)
Machine Specifications
