Xerox PHASER 3125 User Manual

General Procedures and Information
6-20 09/06 PHASER 3124 / PHASER 3125
Firmware Structure and Descriptions
This Engine Control Firmware is a program that controls the laser beam printer engine of the
Phaser 3124 and Phaser 3125. This firmware is executed every 10msec as an interrupt routine
by the main system. At stand-by state, this firmware monitors the enable print command signal
from the main system. If the enable print command signal is detected, this firmware controls the
engine mechanism according to the printing process and paper feeding state.
Engine Control Firmware Overview
• Engine Control Firmware is executed every 10msec by a timer from the main system. And it
consists of 3 control modules.
Engine Main Control
Interface Control and Sensing
Unit Control Module.
• Major operations of the Engine Control Firmware are as follows:
Pick-Up, Feeding and Discharging of Paper Control
LSU Control
HVPS Developer Process Control
Fuser Temperature Control

Xerox PHASER 3125 Specifications

General

Color	No
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	32 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	70 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	8.5 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
