Repairs/Adjustments
PHASER 3124 / PHASER 3125 09/06 4-1
4. Repairs/Adjustments
REP 1 Front Cover Assembly ....................................................................................................4-3
REP 2 Cassette Tray..................................................................................................................4-4
REP 3 Rear Cover .....................................................................................................................4-5
REP 4 Top Cover ......................................................................................................................4-6
REP 5 Left Cover and Right Cover ...........................................................................................4-8
REP 6 Engine Shield .................................................................................................................4-9
REP 7 Fuser Assembly ............................................................................................................4-10
REP 8 HVPS............................................................................................................................4-13
REP 9 SMPS ...........................................................................................................................4-14
REP 10 Main PBA ...................................................................................................................4-15
REP 11 Main Drive Assembly .................................................................................................4-15
REP 12 LSU ............................................................................................................................4-18
REP 13 Paper Path Assembly ................................................................................................4-18

Xerox PHASER 3125 Specifications

General

Color	No
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	32 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	70 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	8.5 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
