General Procedures and Information
PHASER 3124 / PHASER 3125 09/06 6-31
If the paper does not move when you pull, or if you do not see the paper in this area, check the
fuser area around the toner cartridge, PL 1.
2. Open and close the front cover, PL 1 to resume printing the document from failed pages.
In the manual tray
1. Remove the jammed paper in the manual tray, PL 1 by gently pulling it straight out, Figure 5.
Figure 5
If the paper does not move when you pull, or if you do not see the paper in this area, check the
fuser area around the toner cartridge PL 1.
2. Open and close the front cover, PL 1 to resume printing the document from failed pages.

Xerox PHASER 3125 Specifications

General

Color	No
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	32 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	70 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	8.5 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
