Spare Parts List
PHASER 3124 / PHASER 3125 09/06 5-7
PL 3 Fuser Assembly
Item Part Number Description Remark
0 126N00275 FUSER (220V) REP 7
0 126N00274 FUSER (110V) REP 7
1FUSER FRAME
2 FUSER COVER
3 EXIT ROLLER HOLDER
4 FUSER GEAR
5EXIT ROLLER
6SPRING
7 BEARING
8 FUSER GUIDE
9 022N01611 PRESSURE ROLLER
10 022N02310 HEAT ROLLER
11 HEAT ROLLER GEAR
12 RIGHT HEAT BUSH
13 LEFT HEAT BUSH
14 122N00270 HALOGEN LAMP 220V
14 122N00269 HALOGEN LAMP 110V
15 ROLLER RACK
15-1 ROLLER MAIN
15-2 ROLLER FR
15-3 ROLLER HOLDER
15-4 SPRING
16 SPRING PLACE HOLDER
17 LEFT FUSER COVER
18 RIGHT FUSER COVER
19 130N01499 THERMISTOR
20 130N01498 THERMOSTAT
21 THERMOSTAT CAP
22 FUSER HARNESS JOINT
23 STRIPPER FINGER
23-1 SPRING
23-2 FINGER PLATE
23-3 CLAW
24 E-CLIP
25 FUSER DUMMY
26 FUSER GEAR
27 WASHER
28 C-RING

Xerox PHASER 3125 Specifications

General

Color	No
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	32 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	70 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	8.5 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
