Xerox PHASER 3125 User Manual

Spare Parts List
PHASER 3124 / PHASER 3125 09/06 5-9
PL 4 Paper Path Assembly
Item Part Number Description Remark
0 PAPER PATH ASSEMBLY REP 13
1 PAPER PATH GUIDE
2 130N01497 FEED SENSOR ACTUATOR
3 ACTUATOR SPRING
4 015N00558 IPR PLATE SAW
5 VARISTOR GROUND
6 ZENER P GROUND
7 THV GROUND
8 SAW P GROUND
9 HOLDER PAD UNIT
9-1 SPRING
9-2 FRICTION PAD
9-3 HOLDER-M-PAD
10 BUSH HOLDER
11 PICK-UP GEAR
11-1 PICK-UP GEAR B
11-2 PICK-UP GEAR A
11-3 PICK-UP GEAR SPRING
12 SOLENOID
13 FEED GEAR
14 TRANSFER ROLLER RIGHT BUSH
15 TRANSFER ROLLER LEFT BUSH
16 TRANSFER ROLLER SPRING
17 022N02309 TRANSFER ROLLER
18 PTL HOLDER
19 EARTH TRANSFER
20 PICK-UP SHAFT
21 NOT USED
22 PICK-UP ASSEMBLY
22-1 PICK-UP RUBBER HOUSING
22-2 RUBBER PICK UP
23 NOT USED
24 PICK-UP CAM
25 TRANSFER ROLLER GEAR
26 IDLE BAR
27 IDLE ROLLER
28 FEED EXTENSION
29 FEED ROLLER
30 CATCH
31 IDLE RING
32 IDLE ROLL HOLDER

Xerox PHASER 3125 Specifications

General

Color	No
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	32 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	70 W
Power consumption (printing)	400 W
Power consumption (PowerSave)	8.5 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
