Xerox Phaser 3150 - Page 62

Disassembly
5-24
5. Remove the screw from the right idler bushing plate.
6. Remove the plate, idler spring and bushing.
7. Slide the feed shaft idler to the right and out of the printer.
8. Remove the feed roller and feed roller 1 as shown below.
Feed Roller1
Feed Roller
