Xerox Phaser 3150 Service Manual

Alignment and Adjustments
Service Manual 6-5
Code Function Enter LED Stop Remark
00 Motor Motor Run
Motor Stop
01 MHV Mhv On
Mhv off -1550 V
02 THV(-) Thv Negative On
Thv Negative Off
03 THV(+) Thv On
Thv Off +1300 V
04 DEV Dev On
Dev Off +430 V
05 LSU LSU Run
●● ●
On Off Ready
LSU Stop
06 PICK UP Pick Up On
Pick Up Off
07 P EMPTY
●● ●
Paper Empty
08 SENSOR
●● ●
Exit Feed
09 COVER
●● ●
Cover Open
10 Fuser Fuser On Fuser Off 160 C
11 HotBurn HotBurn On
12 Clean Print Clean Printing
13 Thv
Reference
●● ●
Low Adequate High
14 PTL PTL On PTL Off
15 Fan Fan On
Fan Off
16 Regi Clutch Regi Clutch
Regi Clutch Off
17 Regi
Sensor
●● ●
Manual Sensor
18 MP Pickup MP Pickup On MP Pickup Off
19 MP Sensor
●● ●
MP Empty
