Xerox Phaser 7100

Maintenance
Phaser 7100 Color Printer 77
User Guide
10. To close Cover C, raise it slightly, then raise the support rod (1) and snap it into its holder (2).
11. Close Cover C (1), the Toner Cover (2), and Cover A (3).
Cleaning the Density Sensors
If the print or color density is too light, missing, or the background is foggy, clean the density sensors.
CAUTIONS:
• Ensure that nothing touches or scratches the surface of the transfer belt. Scratches,
dirt, or oil from your hands on the belt can deteriorate print quality.
• To protect the imaging units against bright light, close Cover C within 10 minutes.
Longer exposure can deteriorate print quality.
1. Open Cover A.
