Xerox Phaser 8560 System Administrator Guide

Phaser PCL Commands
System Administrator Guide
B-2
Phaser PCL Commands
This section includes:
■ Media Size on page B-2
■ Media Type on page B-3
■ Input Trays on page B-4
■ Output Trays on page B-4
Media Size
The following table lists the most common PCL commands for supported media sizes. For
information on which media sizes are supported in your printer, and the trays that support
them, print the Paper Tips page from your printers control panel.
Media Size PCL 5 Command
*
A3 (297 x 420 mm) <Esc>&l27A
A4 (210 x 297 mm) <Esc>&l26A
A5 (148 x 210 mm) <Esc>&l25A
A6 (105 x 148 mm) <Esc>&l24A
B4-JIS (176 x 257 mm) <Esc>&l46A
B5 Envelope (176 x 250 mm) <Esc>&l100A
B5-ISO (176 x 257 mm) <Esc>&l65A
B5-JIS (182 x 257mm) <Esc>&l45A
SRA3 (320 x 450 mm) <Esc>&l202A
Statement (5.5 x 8.5 in.) <Esc>&l15A
Tabloid (11 x 17 in.) <Esc>&l6A
Tabloid Extra (12 x 18 in.) <Esc>&l201A
Executive (7.25 x 10.5 in.) <Esc>&l1A
Letter (8.5 x 11 in.) <Esc>&l2A
US Folio (8.5 x 13 in.) <Esc>&l10A
Legal (8.5 x 14 in.) <Esc>&l3A
A7 Envelope (5.25 x 7.25 in.) <Esc>&l84A
#10 Commercial Envelope (4.1 x 9.5 in.) <Esc>&l81A
Monarch Envelope (3.8 x 7.5 in.) <Esc>&l80A
C4 Envelope (162 x 229 mm) <Esc>&l93A
C5 Envelope (162 x 229 mm) <Esc>&l91A

Xerox Phaser 8560 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (color, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	3 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	1 MB
Sound power level (standby)	33 dB
Sound pressure level (printing)	54 dB
Maximum duty cycle	85000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c
Maximum input capacity	625 sheets
Paper tray 2 input capacity	525 sheets
Multi-Purpose tray input capacity	100 sheets
Power requirements	110 - 240 V, 50/60 Hz
Networking features	10/100BaseTX
Standard media sizes	140 x 216 mm - 216 x 356 mm
Power consumption (active)	230 W
Compatible operating systems	Linux, Mac OS X 10.2 +, Novell NetWare 3.x +, Windows 2000 +
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	IPv6
Sustainability certificates	ENERGY STAR
Power consumption (PowerSave)	43 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	406 x 533.4 x 368 mm
