Xerox Phaser 8560 System Administrator Guide

Phaser PCL Commands
System Administrator Guide
B-4
Input Trays
The following table lists the most common PCL commands for the input trays supported by
your printer. The table also lists the alternate tray used if the optional input tray is not installed.
Note: When more than one command is listed, you can use either command.
Output Trays
The following table lists the PCL commands and PJL values for the output trays supported by
your printer, if applicable.
Input Trays
Phaser 8560
Phaser 6360 Phaser 4510
PCL 5
Command
Alternate
Tray
PCL 5
Command
Alternate
Tray
Tray 1 n/a n/a <Esc>&l2H
<Esc>&l3H
<Esc>&l4H
<Esc>&l6H
n/a
Tray 1 (MPT) in multi-sheet
mode
<Esc>&l4H
<Esc>&l6H
n/a n/a n/a
Tray 1 (MPT) in manual feed
mode
<Esc>&l2H
<Esc>&l3H
n/a n/a n/a
Tray 2 <Esc>&l1H n/a <Esc>&l1H
<Esc>&l21H
<Esc>&l22H
n/a
Tray 3 <Esc>&l5H Tray 2 <Esc>&l5H Tray 2
Tray 4 <Esc>&l8H
<Esc>&l20H
Tray 1 <Esc>&l8H
<Esc>&l20H
Tray 1
Tray 5 <Esc>&l21H Tray 1 n/a n/a
Autoselect <Esc>&l7H n/a <Esc>&l7H n/a
Current tray/page eject <Esc>&l0H n/a <Esc>&l0H n/a
* The character that follows the “&” in the command is the lowercase letter “L”.
Output Tray PCL 5 Command
*
PJL Value
Top output tray <Esc>&l1G FACEDOWN, UPPER,
STANDARD, or OFFSET
* The character that follows the “&” in the command is the lowercase letter “L”.
** The PJL Value is used with the PJL “OUTBIN” variable.

Xerox Phaser 8560 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (color, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	3 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	1 MB
Sound power level (standby)	33 dB
Sound pressure level (printing)	54 dB
Maximum duty cycle	85000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c
Maximum input capacity	625 sheets
Paper tray 2 input capacity	525 sheets
Multi-Purpose tray input capacity	100 sheets
Power requirements	110 - 240 V, 50/60 Hz
Networking features	10/100BaseTX
Standard media sizes	140 x 216 mm - 216 x 356 mm
Power consumption (active)	230 W
Compatible operating systems	Linux, Mac OS X 10.2 +, Novell NetWare 3.x +, Windows 2000 +
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	IPv6
Sustainability certificates	ENERGY STAR
Power consumption (PowerSave)	43 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	406 x 533.4 x 368 mm
