Xerox VersaLink B400 User Manual

IITTEEMM NNAAMMEE
DDEESSCCRRIIPPTTIIOONN
• When the printer is powered on, pressing this button displays a
menu on the control panel. From this menu, you can choose to
enter Sleep mode, restart, or power off the printer.
• When the printer is powered on, but in a low-power mode or
Sleep mode, pressing this button wakes the printer.
• When the printer is powered on, holding this button for 10-
seconds turns off the printer.
• This button also blinks to indicate the power status of the printer.
• When the light blinks slowly, the printer is in low-power mode or
Sleep mode.
• When the light blinks rapidly, the printer is powering down, or
exiting a low-power mode.
5 Status LED This light blinks blue or amber to indicate printer status.
BBlluuee
• Blinks blue once to acknowledge a successful Authentication
request.
• Blinks blue once slowly for a print job initiated at the control
panel.
• Blinks blue twice slowly for a print job received from the network.
• Blinks blue rapidly while the printer is powering up, or to signal
detection of a Wi-Fi Direct connection request.
AAmmbbeerr
• Blinks amber to indicate an error condition or warning that
requires your attention. For example, an out-of-toner condition, a
paper jam, or out of paper for the current job.
• It also blinks amber to indicate a system error, which typically is
associated with an error code.
6 Notification Banner Notifications and messages are displayed in a pop-up banner below
the apps area. To view the full notification, touch the down arrow.
Once you have reviewed the information, touch XX to close.
7 Pause Button When a job is being processed, a Pause icon appears in the
notification banner area. To pause the current job, touch the Pause
icon. The job pauses with the option to resume or delete the job.
22
Xerox
®
VersaLink
®
B400 Printer User Guide
Getting Started

Xerox VersaLink B400 Specifications

General

N-up printing	2, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	5 s
Time to first page (black, normal)	8 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	28 ppm
PCL fonts	83
Printer fonts	PCL, PostScript
Product color	Blue, Grey
Printing colors	Black
Country of origin	China
Maximum duty cycle	150000 pages per month
Recommended duty cycle	0 - 15000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL/2, HP-RTL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF, XPS
Internal memory	2048 MB
Noise level (ready)	30 dB
Sound power level (standby)	5.3 dB
Sound power level (printing)	7.5 dB
Sound pressure level (printing)	56 dB
USB connector	USB Type-A
Standard interfaces	RJ-45, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Paper tray 1 input capacity	550 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
Custom media width	76.2 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Current rating	6 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	46 W
Power consumption (printing)	565 W
Power consumption (PowerSave)	4 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Mac operating systems supported	Mac OS X 10.9 Mavericks
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, IPSec, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100
Cables included	AC
Included cartridge capacity (black)	5900 pages
Display	LCD
Control type	Touch
Display diagonal	5 \
Market positioning	Business
Languages support	Multi
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210
Export Control Classification Number (ECCN)	EAR99
Package weight	17350 g

Weight and Dimensions

Depth	426 mm
Width	459 mm
Height	339 mm
