Xerox VersaLink B400 User Manual

Installing the Software
Before installing driver software, verify that the printer is plugged in, powered on, connected correctly, and has a
valid IP address. The IP address usually appears in the upper, right corner of the control panel. If you cannot find
the IP address, refer to Finding the IP Address of Your Printer.
If the Software and Documentation disc is not available, download the latest drivers from www.xerox.com/support/
VLB400drivers.
OPERATING SYSTEM REQUIREMENTS
• Windows 7, Windows 8.1, Windows Server 2008, Windows 10, Windows Server 2008 R2, and Windows Server
2012.
• Macintosh OS X version 10.10 and later.
• UNIX and Linux: Your printer supports connection to various UNIX platforms through the network interface.
INSTALLING THE PRINT DRIVERS FOR A WINDOWS NETWORK PRINTER
1. Insert the Software and Documentation disc into the appropriate drive on your computer. If the installer does
not start automatically, navigate to the drive, and double-click the SSeettuupp..eexxee installer file.
2. Select your printer model.
3. Click IInnssttaallll DDrriivveerrss.
4. Select IInnssttaallll PPrriinntt DDrriivveerr.
5. At the License Agreement, click II AAggrreeee.
6. From the list of discovered printers, select your printer.
Note: When installing drivers for a network printer, if your printer does not appear in the list, click the IIPP
AAddddrreessss oorr DDNNSS NNaammeebutton. In the IP Address or DNS Name field, type the IP address of your printer,
then click SSeeaarrcchh to locate and select your printer. If you do not know the IP address of the printer, refer to
Finding the IP Address of Your Printer.
7. Click NNeexxtt.
8. If needed, you can name your printer by typing a name in the QQuueeuuee NNaammee field.
9. Select a Print Driver.
10. Click IInnssttaallll.
11. If needed, set the printer as the default printer.
Note: Before selecting SShhaarree PPrriinntteerr, contact your system administrator.
12. To complete the installation, click FFiinniisshh, then click CClloossee.
INSTALLING THE PRINT DRIVERS FOR A WINDOWS USB PRINTER
1. Insert the Software and Documentation disc into the appropriate drive on your computer. If the installer does
not start automatically, navigate to the drive, and double-click the SSeettuupp..eexxee installer file.
Xerox
®
VersaLink
®
B400 Printer User Guide 51
Getting Started

Xerox VersaLink B400 Specifications

General

N-up printing	2, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	5 s
Time to first page (black, normal)	8 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	28 ppm
PCL fonts	83
Printer fonts	PCL, PostScript
Product color	Blue, Grey
Printing colors	Black
Country of origin	China
Maximum duty cycle	150000 pages per month
Recommended duty cycle	0 - 15000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Page description languages	HP-GL/2, HP-RTL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF, XPS
Internal memory	2048 MB
Noise level (ready)	30 dB
Sound power level (standby)	5.3 dB
Sound power level (printing)	7.5 dB
Sound pressure level (printing)	56 dB
USB connector	USB Type-A
Standard interfaces	RJ-45, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Paper tray 1 input capacity	550 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
Custom media width	76.2 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Current rating	6 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	46 W
Power consumption (printing)	565 W
Power consumption (PowerSave)	4 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Mac operating systems supported	Mac OS X 10.9 Mavericks
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, IPSec, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100
Cables included	AC
Included cartridge capacity (black)	5900 pages
Display	LCD
Control type	Touch
Display diagonal	5 \
Market positioning	Business
Languages support	Multi
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210
Export Control Classification Number (ECCN)	EAR99
Package weight	17350 g

Weight and Dimensions

Depth	426 mm
Width	459 mm
Height	339 mm
