Installation Xerox
®
Versant™ 2100 Press
Customer Expectation and Installation Guide Xerox Confidential 39
2. If yes, may the carrier move the equipment at the loading dock
and/or the installation site?
Yes No
3. Can the delivery be made during normal business hours?
Yes No
4. If no, identify any special delivery instructions on the Analyst Site
Worksheet, located later in this chapter.
Yes No
5. (USA only) Are union workers at the loading dock and/or the
installation site?
Yes No
Docks
1. Is there a loading dock?
Yes No
2. Is the dock accessible to a truck/trailer for delivery?
Yes No
Write any special instructions for the truck driver:
3. Does the dock have load/dock levelers?
Yes No
If no: A fork lift may be required.
4. Does the dock area have adequate space for unloading the Press?
Yes No
NOTE: If the answer to any of the above questions is No, then a fork lift
will be required to unload the modules from the truck to the floor/ground
level.
Forklift Requirements
If a forklift is needed for lifting and unloading the print engine modules,
refer to the following forklift requirements:
The print engine (left and right sides) can be moved by either the long or
short side of the either module. If lifted from the front-to-rear, make
sure that a gap exists between the vertical portion of the fork and the
print engine module.
NOTE: Forks should not be fully inserted to reduce potential damage to
the front covers or rear electrical panels.
Minimum forklift capacity is 6,500 lb. (2,952 kg).
Minimum fork length is 60 in. (152 cm), measuring outside the fork
packet.
Maximum fork width is 5 1/4 in. (133 mm).
Fork spacing is 24 in. (610 mm).
Inside fork pocket dimensions of the press are 5 3/4 in. (146 mm) wide x
2 3/4 in. (70 mm) high.
If forklift extensions/spreader bars are to be used, the maximum fork
width allowed is 5
1
/
4
in. (133 mm), and the maximum thickness can be 2
1
/
2
in. (63.5 mm).
NOTE: Spreader bars must be oriented with the forklift loop toward the
front of the press modules (left and right). Forklift extensions are only to
be used by Xerox authorized carriers.
Entrance Ways
Measure entrance ways; they must be wide enough to accommodate the
Advanced HCF dimensions of 39 in / 9960.6 mm by 32 in / 812.8 mm of
the Press. Is there proper clearance?
Yes No
If No, try another entrance or the site must be modified.
Stairs
Are there stairs anywhere in the delivery path?
Yes No
TIP: If there are any stairs in the delivery path, the Carrier Delivery Site
Inspection must be performed prior to delivery commitment.
WARNING: The Xerox press and print server should never be up-ended or
serious damage will result.
Elevator Requirements
Elevator Weight Requirements
An elevator capacity of 1200 lb. (545 kg) or more is required to move the
press and print server for an installation. If the elevator capacity is not
adequate, options may exist for elevator modifications. Please contact the
on-site maintenance support for more information on this process.
Does the elevator capacity equal or exceed 1200 lbs. (545 kg) capacity?
Yes No
If no: Determine whether modifications can be made to the elevator to
increase its maximum weight capacity to 1200 lbs. (545 kg). If
modifications cannot be made, the elevator cannot be used.
Elevator Width Requirements
The elevator width requirements include the doorway entrance and the
interior area. Measure the elevator entrance and interior dimensions, is there
sufficient space to accommodate the press modules?
Yes No
If No and the elevator opening is too narrow, determine whether there is
another means of transporting the press and the print server to the
installation location.
Ramps
Are there any ramps on the installation route?
Yes No
If Yes:
Ensure that the slope of the ramp is less than 20 degrees. Excessive
sloping can cause shifting of internal components that can affect
subsystem settings and impact the performance of the press.
More than a two-man crew may be required during the installation.
