EDC Mode
General Procedures and Information
EDC Mode
The following diagnostic routines can be accessed in EDC Mode. Refer to Table 1 for a com-
plete listing of Test Routine options.
• DC131 NVM Read/Write
The NVM Read/Write routine provides the capability to review and modify machine con-
trol parameters stored in Non-Volatile Memory (NVM). Refer to Table 1.
• DC132 NVM Initialize
The NVM Initialize routine provides the capability to initialize (set to default) machine con-
trol parameters stored in Non-Volatile Memory (NVM). Refer to Table 1
• DC330 Test Routines
This routine provides the capability to verify component functionality by monitoring input
signals and controlling output states. Refer to Table 2.
Table 1 NVM Codes and values
NVM Code LCD Definition Default Min Max
105 MHV Bias Charger HV Black DC Duty 210 50 250
106 Deve Bias Deve DC Black 190 50 250
107 ATTR bias Transfer2 HV 130 50 250
109 Fuser Heat Standby target temperature 10 0 15
110 LSU LSU Power at Normal Speed 450 50 600
Table 2 Input/Output Components
Diagnostic
Code Displayed name Definition
Input/
Output
State
Displayed
100 Motor Main BLDC Main Feed (BLDC) Motor
is On/Off
Output [Off]
Main BLDC Rdy Detect if Main Feed
(BLDC) Motor runs at
normal speed
Input [Off]
101 Clutch Tray 1 Pick up Engages drive to pick up
a paper from tray1
Output [Off]
Registration Engages drive to regis-
tration rolls
Output [Off]
Out Bin Full Detects when the output
tray is full
Output [Low]
102 Sensor Tray 1 Empty Detects when a sheet is
in Tray1
Input [Low]
Feed Sens Detects when a sheet is
at Feed sensor
Input [Low]
Regi Sens Detects when a sheet is
at registration sensor
Input [Low]
Exit Sens Detects when a sheet is
at Exit sensor
Input [Low]
105 Charger K MHV Bias Black MHV bias voltage
on at normal drive level
Output [Off]
106 Develop-
ment
K Dev Bias Black Dev bias voltage
on at normal drive level
Output [Off]
107 Transfer K THV Bias Black THV bias voltage
on at normal drive level
Input [Off]
K THV(-) Bias Black THV bias voltage
on at normal drive level
Input [Off]
K THV(-) BiasR Black THV bias voltage
109 Fuser Fuser Heat Temp A Detects what the temper-
ature A is on fuser.
Input Numeric 3
digits
110 LSU LSU Motor1 Rdy Detects if LSU motor1
runs at normal speed
Input [Low]
LSU Motor1 Run LSU Motor1 On/Off Output [Off]
LSU LD Power4 LSU LD4 Power On/Off
(black)
Output [Off]
LSU HSync4 Horizontal Sync Input [Low]
