Xerox WorkCentre 5222 User Manual

February, 2008
6-41
WorkCentre 5225, 5230
IIT NVM List
General Procedures
Launch Version
715-720 Normal Density Text (BW Copy) 128 0~256 B/W COPY Text Normal Density Adjustment
715-721 High Density Text (BW Copy) 128 0~256 B/W COPY Text Darker 3 Density Adjustment
715-722 Normal Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Normal Density Adjustment
715-723 High Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Darker 3 Density Adjustment
715-724 PLTN RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for Platen model. BASE, HAEST,
MAESST, NAESS
715-725 DADF-P-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model Platen job. Or, Slow
Scan Non-detection area Setup Value at Real Time AE for CVT job. BASE, HAEST, MAESST,
NAESS
715-726 DADF-D-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model DADF job. BASE,
HAEST, MAESST, NAESS
715-780 B-Hue Start Degree 270 0~360 The value can be set in 1 degree (C) increments
715-781 B-Hue End Degree 320 0~360 The value can be set in 1 degree (C) increments
715-782 G-Hue Start Degree 110 0~360 The value can be set in 1 degree (C) increments
715-783 G-Hue End Degree 200 0~360 The value can be set in 1 degree (C) increments
715-784 R-Hue Start Degree 350 0~360 The value can be set in 1 degree (C) increments
715-785 R-Hue End Degree 60 0~360 The value can be set in 1 degree (C) increments
715-786 Y-Hue Start Degree 60 0~360 The value can be set in 1 degree (C) increments
715-787 Y-Hue End Degree 120 0~360 The value can be set in 1 degree (C) increments
715-788 M-Hue Start Degree 320 0~360 The value can be set in 1 degree (C) increments
715-789 M-Hue End Degree 10 0~360 The value can be set in 1 degree (C) increments
715-790 C-Hue Start Degree 190 0~360 The value can be set in 1 degree (C) increments
715-791 C-Hue End Degree 280 0~360 The value can be set in 1 degree (C) increments
715-800 IISS-DADF Communication Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-801 IISS-DADF Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-802 IISS-Controller Communication Fail (Overall
Tot al)
0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-803 IISS-Controller Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-804 DADF EEPROM Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-805 DADF EEPROM Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-806 IPS Fan Failure Count (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-807 IPS Fan Failure Count (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-808 CRG Position Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-809 CRG Position Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-810 IISS LOGIC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-811 IISS LOGIC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-814 Lamp Illumination Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-815 Lamp Illumination Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-816 CRG Over Run Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-817 CRG Over Run Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-818 Lamp Fan Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
Table 2 IISS
Chain-Link Content Default Range Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
