Xerox WorkCentre 5222 User Manual

February, 2008
6-42
WorkCentre 5225, 5230
IIT NVM List
Launch Version
General Procedures
Chain 719-xxx Configuration
715-819 Lamp Fan Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-820 CCD Fan Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-821 CCD Fan Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-822 AGC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-823 AGC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-824 AOC Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-825 AOC Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-826 IPS PWBA Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-827 IPS PWBA Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-828 IISS/EXT Communication Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-829 IISS/EXT Communication Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-830 Extension EEPROM Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-831 Extension EEPROM Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-832 IPS-EXT Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-833 IPS-EXT Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-834 IPS-YATA Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-835 IPS-YATA Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-836 EXT-YATA Connection Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-837 EXT-YATA Connection Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-838 YATA PWBA Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-839 YATA PWBA Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-840 ITS PWBA Memory Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-841 ITS PWBA Memory Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-856 IIT Hot Line Fail (Overall Total) 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-857 IIT Hot Line Fail (Since Reset) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-860 Scan Replacement Life Count (upper digits) 91 0~65535 Scan Replacement Life Count (upper digits) (write not permitted): 6,000,000 times (including Pre
Scan)
715-861 Scan Replacement Life Count (lower digits) 36224 0~65535 Scan Replacement Life Count (lower digits) (write not permitted): 6,000,000 times (including Pre
Scan)
715-875 Lamp On Time Replacement Life Count (upper
digits)
109 0~65535 Lamp On Time Replacement Life Count (upper digits) (write not permitted): 7,200,000 sec. (2,000
hr.)
715-876 Lamp On Time Replacement Life Count (lower
digits)
56576 0~65535 Lamp On Time Replacement Life Count (lower digits) (write not permitted): 7,200,000 sec. (2,000
hr.)
715-890 Lamp On Replacement Life Count (upper digits) 91 0~65535 Lamp On Replacement Life Count (upper digits) (write not permitted): 6,000,000 times
715-891 Lamp On Replacement Life Count (lower digits) 36224 0~65535 Lamp On Replacement Life Count (lower digits) (write not permitted): 6,000,000 times
Table 2 IISS
Chain-Link Content Default Range Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
