February, 2008
6-43
WorkCentre 5225, 5230
IIT NVM List
General Procedures
Launch Version
Controller & Fax NVM List
Chain 700-xxx Common
Table 3 Configuration
Chain-Link Name Default Range Remarks
719-008 Market Information 0 0~4 0: FX, 1: AP, 2: XC, 3: XE, 4: SA *NVM value is updated when the power is turned on according to
the market information of the SystemCapabilitiesUpdate command
719-009 IISS Major Version 0 0~65535 IISS Major Version Number (Same as when downloaded)
719-010 IISS Minor Version 0 0~65535 IISS Minor Version Number (Same as when downloaded)
719-011 IISS Revision Version 0 0~65535 IISS Revision Version Number (Same as when downloaded)
719-012 IISS Patch Version 0 0~65535 IISS Patch Version Number (Same as when downloaded)
719-013 ADF Major Version 0 0~65535 ADF Major Version Number (Same as when downloaded)
719-014 ADF Minor Version 0 0~65535 ADF Minor Version Number (Same as when downloaded)
719-015 ADF Revision Version 0 0~65535 ADF Revision Version Number (Same as when downloaded)
719-016 ADF Patch Version 0 0~65535 ADF Patch Version Number (Same as when downloaded)
719-017 IPL Version 0 0~65535 IPL Version Number
Table 1 Common
Chain-
Link
Content Default Range Meaning
700-006 Configuration - 1~15 P(rinter), F(ax), C(opy), S(can) are allocated the following bits and are expressed in the fol-
lowing logic. P: 01, F: 02, C 04, S: 08. To differentiate between SP and MF-CSP, SP is allo-
cated 0x09.
700-061 Fax Card Available - -2~0 0: Normal, -1: Error, -2: Not installed
700-064 Fax Card Available for Ch0 0=None 0~1 0=None, 1=Available (Implemented on Host. Only automatic detection is necessary for Fax
card.)
700-071 USB User Buffer Size 64KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-073 Page Memory Size - 64~256 bytes (Auto Set)
700-075 ART User Buffer Size 32KB 32~2048 [32KB~2048KB] (32KB increments) Unit: Kbyte
700-076 PostScript Buffer Size 24MB (24x1024) 16~96 [16MB~96MB] (0.25MB increments) Unit: Kbyte (Valid when PS option is available)
700-078 Form Buffer Size 128KB 128~2048 [128KB~2048KB] Unit: Kbyte
700-080 HPGL/Auto Layout Buffer Size 64KB 64~5120 [64KB~5120KB] (32KB increments) Unit: Kbyte
700-081 Parallel Buffer Size 64KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-082 Port9100 Buffer Size 256KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-083 Lpd Buffer Size 1024KB 1024~2048 [1MB~2MB] (32KB increments) Unit: Kbyte
700-084 NetWare Buffer Size 256KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-085 AppleTalk Buffer Size 1024KB 1024~2048 [1MB~2MB] (32KB increments) Unit: Kbyte
700-086 SMB Buffer Size 256KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-087 IPP Buffer Size 256KB 64~1024 [64KB~1MB] (32KB increments) Unit: Kbyte
700-089 HDD Status - -2~0 [0: Installed, -1: Failed, -2: Not installed] (Auto Detect)
700-100 Forced Warmup Function Enable 0 0~1 0: Cannot be set, 1: Can be set
700-109 Forced Warmup Mode 0 0~1 0: Disable, 1: Enable
700-110 Forced Warmup Time (Hour) 23 0~23 0 to 23 (Hour)
700-111 Forced Warmup Time (Minute) 59 0~59 0 to 59 (Minute)
