February, 2008
6-48
WorkCentre 5225, 5230
Launch Version
General Procedures
700-329 SEEPROM Product Code (1st digit) - Alphanumerics (ASCII)
700-330 SEEPROM Product Code (2nd digit) - Alphanumerics (ASCII)
700-331 SEEPROM Product Code (3rd digit) - Alphanumerics (ASCII)
700-332 SEEPROM Product Code (4th digit) - Alphanumerics (ASCII)
700-333 SEEPROM Product Code (5th digit) - Alphanumerics (ASCII)
700-334 SEEPROM Product Code (6th digit) - Alphanumerics (ASCII)
700-335 SEEPROM Product Code (7th digit) - Alphanumerics (ASCII)
700-336 SEEPROM Product Code (8th digit) - Alphanumerics (ASCII)
700-337 Configuration (Info. on SEEPROM) - [P, SP, CSP, CFSP (,C)] (C is requested by M/N) Adjusted at Factory Settings P(rinter),
F(ax), C(opy), S(can) are allocated the following bits and are expressed in the following
logic. P: 0x01, F: 0x02, C: 0x04, S: 0x08 (700-006 works in connection)
700-338 Territory (SEEPROM) - 1~4 [1=FX, 2=XC, 3=XE, 4=AP]
700-368 Lpd Buffer Size (Memory Spool) 1MB (1x1024) 512~32768 When spooling memory: [512KB~32MB] (256KB increments) Unit: Kbyte
700-370 SA Group DN Null ASCII 255 bytes
700-371 AA Group DN Null ASCII 255 bytes
700-372 LDAP Search Filter Null ASCII 512 bytes
700-390 Memory Size for E-mail Print 256 64~1024 64K~1MB Unit: Kbyte
700-396 Auditron Color Mode for Copy 0: Prohibit 0~2 0: Prohibit, 1: BW, 2: BW & Low Price Color
700-397 Default Input Medium Size 44: Letter 5: A4, 44: Letter
700-398 CE Auditron Mode 1 0~1 0: Do not display, 1: Display
700-399 Default Unit of Measure (mm/inch) 1 1~3 1: mm, 3: Inch
700-401 Paper Size Group NVM Value set in Paper Size
Group
1~5 [1: Japan, 2: NA (North America), 3: EU, 4: AP, 5: SA (South America)] (Factory set value
SEEPROM.)
700-402 Paper Size Group SEEPROM Set for each region 1~5 [1: Japan, 2: NA (North America), 3: EU, 4: AP, 5: SA (South America)]
700-404 802.1x Authentication Enable 0 0~1 0: Disable, 1: Enable
700-405 802.1x Authentication Type 0 0~2 0: EAP_MDS, 1: EAP_MSCHAPv2, 2: EAP_PEAP_MSCHAPv2
700-406 802.1x Authentication User Name Null ASCII character string of 128 bytes or less (null-terminated)
700-407 802.1x Authentication Password Null ASCII character string of 128 bytes or less (null-terminated)
700-408 802.1x Authentication Validate Certificate 0 0~1 0: Disable, 1: Enable (valid only in the case of EAP_PEAPv0/EAP_MSCHAPv2)
700-410 RAM Disk Size for Print Standard Memory, 33M
Additional 128M, 50M
Additional 256M, 66M
This setting is valid only when the HDD is not installed while the Printer Kit is installed. Do
not set for other cases. The setting range is 0~[current value + available memory capacity].
Unit is 1M. The current value can be checked using the Settings List report. The available
memory capacity can be checked in the Control Panel or the CWIS Memory Settings menu.
Note 1: If a value above [current value + available memory capacity] is entered, Factory Set
-
tings for all memory settings (including Host IF Receive Buffer, Form Memory etc.) will be
restored. Note 2: If the field for Auto Collate printing is also changed, change so that the sum
of all increments does not exceed the available memory capacity. Note 3: If set to 0, Auto
Collate will be turned off. When setting to 0, always set both this setting and the field for
Auto Collate printing to 0.
Table 1 Common
Chain-
Link Content Default Range Meaning
To Next Page
