Xerox WorkCentre 5222 User Manual

February, 2008
6-58
WorkCentre 5225, 5230
Launch Version
General Procedures
711-142 DADF Tail Edge Fine Adjustment (Side1) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-029 to 711-037 with specified data.
711-143 DADF Tail Edge Fine Adjustment (Side2) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-043 to 711-051 with specified data.
711-144 Vertical Ratio Fine Adjustment Replace All 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor. Rewrites all data of 711-057 to 711-065 with specified data.
711-145 T/A Roll Transport Speed Adjustment (Side1)
Replace All
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor. Rewrites all data of 711-070 to 711-078 with specified
data.
711-146 T/A Roll Transport Speed Adjustment (Side2)
Replace All
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor. Rewrites all data of 711-080 to 711-088 with specified
data.
711-150 Loop Amount Adjustment (Side1) (x1 Pulse) 3 0~9 0.6835mm Initial value 3.6mm (172 pulse, 130 pulse for High Speed mode) +4.1mm/-2.1mm 10
pulse increments
711-151 Loop Amount Adjustment (Side2) (x6 Pulse) 5 0~14 0.4581mm Initial value 4.0mm (256 pulse) +4.1mm (346 pulse) / -2.3mm (206 pulse) 10 pulse
increments
711-152 Simplex Speed Mode Switch 0 0~1 - 0: High Speed mode Off 1: High Speed mode On
711-158 Position Adjustment for End Position during Invert
(x4 Pulse)
10 20 0.4581mm Initial value 31.1mm (450 pulse) +4.6mm (766 pulse) / -4.6mm (566 pulse) 10 pulse
increments
711-164 Slow Scan Original Size Correction Value 50 0~100 0.1mm Correction value for [Size Detection Auto-Correction Function] Original Size Correc-
tion Value: +/-5mm
711-200 Position Adjustment for Pre Regist End Position
(Original Lead Edge Eject Amount from Regi Roll
in x2 Pulse Increments)
8 0~16 0.6249mm Initial value 0mm (0 pulse) +5.0mm (80 pulse) / -5.0mm (-80 pulse) 10 pulse incre-
ments This value also applies to Scan Position Transport Time.
711-201 Position Adjustment for Feed Motor Off Start Posi-
tion (x3 Pulse)
8 1~15 0.6249mm Initial value 5.0mm (80 pulse) +4.4mm (150 pulse) / -4.4mm (10 pulse) 10 pulse
increments
711-202 Position Adjustment for Position to Start Increasing
Speed in Duplex (x5 Pulse)
10 0~20 0.4581mm Initial value 50.4mm (1080 pulse) +4.6mm (1180 pulse) / -4.6mm (980 pulse) 10
pulse increments
711-203 Position Adjustment for First-Out Pre Feed Posi-
tion in Duplex (x7 Pulse)
5 0~10 0.6835mm Initial value 14.6mm (224 pulse) +3.4mm (274 pulse) / -3.4mm (174 pulse) 10 pulse
increments
711-204 Position Adjustment for N.R. Solenoid On Position
during Invert Output (x8 Pulse)
10 0~20 0.4581mm Initial value 15.0mm (241 pulse) +4.6mm (341 pulse) / -4.6mm (141 pulse) 10 pulse
increments
711-205 Side2 Feed Motor Reverse Start Time Adjustment
Value (T1 ms)
4 0~20 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-207 Next Feed Start Time Adjustment Value (T3 ms) 5 2~27 4msec Initial value 0m +88ms/-12ms, 4ms increments
711-208 Simplex Next Pre Regist Start Time Adjustment
Value (T4 ms)
6 6~25 4msec Initial value 4ms +76ms/0ms, 4ms increments
711-209 Invert Start Time Adjustment Value (T6 ms) 5 0~25 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-210 N.R. Solenoid On Start Time Adjustment Value
during Invert Output (T7 ms)
5 0~15 4msec Initial value0ms +40ms/-20ms, 4ms increments
711-211 First-Out Original Feed Start Time Adjustment
Value (T8 ms)
5 0~25 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-212 Duplex Next Pre Regist Start Time Adjustment
Value (T9 ms)
6 6~25 4msec Initial value 4ms +76ms/0ms, 4ms increments
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
