Xerox WorkCentre 5222 User Manual

February, 2008
6-59
WorkCentre 5225, 5230
General Procedures
Launch Version
711-213 DADF Stamp Solenoid On Time Adjustment 5 3~20 2msec Initial value 10ms +30ms/-4ms, 2ms increments
711-214 DADF Stamp Position Adjustment 15 0~30 0.5mm Initial value 0mm +7.5mm/-7.5mm, approx. 0.5mm increments Initial value is 10mm
from Tail Edge.
711-215 Slow Down Start Time Adjustment Value during
Nudger Lift Down (T11 ms)
10 0~20 4msec Initial value 0ms +/-40ms, 4ms increments
711-216 Slow Down Start Time Adjustment Value during
Nudger Lift Up (T12 ms)
10 10~20 4msec Initial value0ms +40ms/-0ms, 4ms increments
711-217 Feed Out Sensor Static Jam Detection Sampling
No. Setting
20 1~40 1 time Initial value 20 times +20 times/-19 times, 1 time increments
711-218 Feed Out Sensor Act. Correction Coefficient - A9 59 0~255 0.01 Initial value 0.59 0.00~2.55, 0.01 increments
711-219 Feed Out Sensor Act. Correction Coefficient - B9 104 0~255 1 Initial value 104 0~255, 1 increments
711-270 ADF-IIT Combine Adjustment Value Data 1 0 0~255 - Adjustment Value Data 1 sent to IIT during ADF-IIT Combine.
711-271 ADF-IIT Combine Adjustment Value Data 2 0 0~255 - Adjustment Value Data 2 sent to IIT during ADF-IIT Combine.
711-272 ADF-IIT Combine Adjustment Value Data 3 0 0~255 - Adjustment Value Data 3 sent to IIT during ADF-IIT Combine.
711-273 ADF-IIT Combine Adjustment Value Data 4 0 0~255 - Adjustment Value Data 4 sent to IIT during ADF-IIT Combine.
711-274 ADF-IIT Combine Adjustment Value Data 5 0 0~255 - Adjustment Value Data 5 sent to IIT during ADF-IIT Combine.
711-275 ADF-IIT Combine Adjustment Value Data 6 0 0~255 - Adjustment Value Data 6 sent to IIT during ADF-IIT Combine.
711-276 ADF-IIT Combine Adjustment Value Data 7 0 0~255 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine.
711-277 ADF-IIT Combine Adjustment Value Data 8 0 0~255 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine.
711-278 ADF-IIT Combine Adjustment Value Data 9 0 0~255 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine.
711-279 ADF-IIT Combine Adjustment Value Data 10 0 0~255 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine.
711-280 ADF-IIT Combine Adjustment Value Data 11 0 0~255 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine.
711-281 ADF-IIT Combine Adjustment Value Data 12 0 0~255 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine.
711-282 ADF-IIT Combine Adjustment Value Data 13 0 0~255 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine.
711-283 ADF-IIT Combine Adjustment Value Data 14 0 0~255 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine.
711-284 ADF-IIT Combine Adjustment Value Data 15 0 0~255 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine.
711-297 Communication Fail Bypass 0 0~1 - 0: Disable Communication Fail Bypass 1: Enable Communication Fail Bypass
711-468 DADF Open/Close Life Count (upper digits) 3 0~65535 - 260K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-469 DADF Open/Close Life Count (lower digits) 63392 0~65535 -
711-470 DADF Document Feed Life Count (upper digits) 3 0~65535 - 200K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-471 DADF Document Feed Life Count (lower digits) 3392 0~65535 -
711-472 DADF Simplex and Duplex Document Feed Life
Count (upper digits)
13 0~65535 - 912K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-473 DADF Simplex and Duplex Document Feed Life
Count (lower digits)
60032 0~65535 -
711-474 Invert Solenoid Life Count (upper digits) 7 0~65535 - 500K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-475 Invert Solenoid Life Count (lower digits) 41248 0~65535 -
711-476 DADF Stamp Solenoid Life Count (upper digits) 1 0~65535 - 100K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
