WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
071-110 EXIT SENSOR2 L with paper EXIT
071-200 TRAY4 SIZE digital SENSOR L It is used for size detection auxiliary. TTM does not have Digital Sensor (always
0)
071-201 TRAY1 NO PAPER SENSOR L Without paper Not Available
071-202 TRAY2 NO PAPER SENSOR L Without paper Not Available
071-203 TRAY3 NO PAPER SENSOR L Without paper Not Available
071-204 TRAY4 NO PAPER SENSOR L Without paper Not Available
071-205 MPT NO PAPER SENSOR L Without paper Not Available
071-206 TRAY1 LEVEL SENSOR L Lifted up (Lifter is at paper feeding position) Not Available
071-207 TRAY2 LEVEL SENSOR L Lifted up (Lifter is at paper feeding position) Not Available
071-208 TRAY3 LEVEL SENSOR L Lifted up (Lifter is at paper feeding position) Not Available
071-209 TRAY4 LEVEL SENSOR L Lifted up (Lifter is at paper feeding position) Not Available
071-210 TRAY1 SIZE digital SENSOR L It is used for size detection auxiliary. Not Available
071-211 TRAY2 SIZE digital SENSOR L It is used for size detection auxiliary. Not Available
071-212 TRAY3 SIZE digital SENSOR L It is used for size detection auxiliary. TTM does not have Digital Sensor (always
0)
071-213 FEED READY SIGNAL H Level is high. Hot-Line Control Not Available
071-230 TRAY1 SIZE SENSOR Analog Min 0, Max 1023 Current Tray 1 Size Sensor A/D value,
monitor
071-231 TRAY2 SIZE SENSOR Analog Min 0, Max 1023 Current Tray 2 Size Sensor A/D value,
monitor
071-232 TRAY3 SIZE SENSOR Analog Min 0, Max 1023 Current Tray 3 Size Sensor A/D value,
monitor
071-233 TRAY4 SIZE SENSOR Analog Min 0, Max 1023 Current Tray 4 Size Sensor A/D value,
monitor
071-234 MSI SIZE SENSOR Analog Min 0, Max 1023 Current SMH Size Sensor A/D value, moni-
tor
071-300 Left Hand COVER L Cover is open (Interlock switch off) Not Available
071-301 TRAY MODULE COVER L Cover is open (Interlock switch off) Not Available
071-302 Left Hand Low COVER H Cover is open (Interlock switch off) Not Available
071-303 FRONT COVER L Cover is open (Interlock switch off) When Left Hand Cover open, the Front
Cover status can not be detected due to
the hardware mechanism. Therefore the
Front Cover is considered as “closed”
regardless of the Front Cover being open/
closed.
071-304 Left Hand High COVER H Cover is open (Interlock switch off) EXIT
071-305 DUP INTERLOCK H open Not Available
073-200 FUSER FAN FAIL MONITOR SIGNAL H Not Available
078-100 HCF Prefeed Sensor H With paper Not Available
078-101 HCF Feed Out Sensor H With paper Not Available
078-201 HCF No Paper Sensor L Without paper Not Available
Table 1 Input Component Control Codes IOT
