Xerox WorkCentre 5222 User Manual

February, 2008
6-127
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
078-202 HCF Size Sensor A - Paper size Not Available
078-203 HCF Size Sensor B - Paper size Not Available
078-204 HCF Tray In Sensor H Tray inserted Not Available
078-205 HCF Level Sensor H Lift up Not Available
078-300 HCF Transport Interlock H Cover is open (Interlock Switch off) Not Available
078-301 HCF Side Out Switch H Open Not Available
089-100 Registration SENSOR L with paper Not Available
089-101 Registration SENSOR (DM) H with paper Sensor level detected by DM DM
089-200 Registration CLUTCH (DM) L in ON state Signal detected by DM MODULE DM
089-201 Registration CLUTCH(EXIT) L in ON state Signal detected by EXIT MODULE EXIT
091-200 DRUM DETECT L EP Cartridge installed Not Available
092-200 Temperature Sensor Analog Min 140, Max 710 Not Available
092-201 Humidity Sensor Analog Min 36, Max 400 Not Available
092-202 ATC Sensor Analog Min 200, Max 800 Not Available
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level
Meaning Timer Off Cycle Operation Remarks
012-013 Sub Paddle Solenoid ON/OFF L = ON Same as Name X X 100 ms (B/C-Finisher)
660 ms (A-Finisher)
250 ms (SB-Finisher)
012-018 Transport Motor Reverse ON/OFF - Same as Name X X Reverse rotation
012-020 Front Tamper Motor Low FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-021 Front Tamper Motor Middle FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-022 Front Tamper Motor High FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-023 Front Tamper Motor Low REAR ON/OFF Pulse ON Same as Name X X Not Available
012-024 Front Tamper Motor Middle REAR ON/
OFF
Pulse ON Same as Name X X Not Available
012-025 Front Tamper Motor High REAR ON/OFF Pulse ON Same as Name X X Not Available
012-026 Rear Tamper Motor Low FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-027 Rear Tamper Motor Middle FRONT ON/
OFF
Pulse ON Same as Name X X Not Available
012-028 Rear Tamper Motor High FRONT ON/OFF Pulse ON Same as Name X X Not Available
012-029 Rear Tamper Motor Low REAR ON/OFF Pulse ON Same as Name X X Not Available
012-030 Rear Tamper Motor Middle REAR ON/
OFF
Pulse ON Same as Name X X Not Available
012-031 Rear Tamper Motor High REAR ON/OFF Pulse ON Same as Name X X Not Available
012-032 Xport Motor 1 ON/OFF - Same as Name X X Forward rotation: highest speed
012-033 Xport Motor 2 ON/OFF - Same as Name X X Forward rotation: high speed
Table 1 Input Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
