Xerox WorkCentre 5222 User Manual

February, 2008
6-128
WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
012-034 Xport Motor 3 ON/OFF - Same as Name X X Forward rotation: medium high speed
012-035 Xport Motor 4 ON/OFF - Same as Name X X Forward rotation: medium speed
012-036 Transport Motor 1 ON/OFF - Same as Name X X Forward rotation: high speed
012-037 Transport Motor 2 ON/OFF - Same as Name X X Forward rotation: medium speed
012-038 Transport Motor 3 ON/OFF - Same as Name X X Forward rotation: low speed
012-039 Xport Motor Reverse ON/OFF - Same as Name X X Reverse rotation
012-040 Stapler Move Motor Low FRONT ON/OFF - Same as Name X X Not Available
012-042 Stapler Move Motor High FRONT ON/OFF - Same as Name X X Not Available
012-043 Stapler Move Motor Low REAR ON/OFF - Same as Name X X Not Available
012-045 Stapler Move Motor High REAR ON/OFF - Same as Name X X Not Available
012-046 Staple Motor FORWARD ON/OFF H Same as Name X X Not Available
012-047 Staple Motor REVERSE ON/OFF H Same as Name X X Not Available
012-050 Set Clamp Clutch ON/OFF L = ON Set Clamp Paddle rotation X X 200 ms
012-051 Set Clamp Paddle - Same as Name X X Not Available
012-052 Eject Clamp Motor Up ON/OFF Pulse ON Eject Clamp Roller moves up X X Motor forward rotation: high speed
012-053 Eject Clamp Motor Down ON/OFF Pulse ON Eject Clamp Roller moves down X X Motor reverse rotation: high speed
012-054 Eject Motor Low Forward ON/OFF Pulse ON Same as Name X X Motor forward rotation: low speed
SB-Finisher: 1136 pulses
Other Finishers: 2000 pulses
012-055 Eject Motor High Forward ON/OFF Pulse ON Same as Name X X Motor forward rotation: high speed
SB-Finisher: 1136 pulses
Other Finishers: 2000 pulses
012-060 Stacker Motor UP ON/OFF H Same as Name X X Not Available
012-061 Stacker Motor DOWN ON/OFF H Same as Name X X Not Available
012-074 Puncher Motor home Pulse ON Puncher Motor moves to home posi-
tion
X X
012-077 2-Hole Puncher Motor ON/OFF H = ON 2-Hole Puncher Motor moves away
from home position
X X
012-078 3-Hole Puncher Motor ON/OFF H = ON 3-Hole Puncher Motor moves away
from home position
X X
012-079 4-Hole Puncher Motor ON/OFF H = ON 4-Hole Puncher Motor moves away
from home position
X X
012-080 Main Drive Motor ON/OFF L Same as Name X X Not Available
012-081 Eject Motor FORWARD ON/OFF - Same as Name X X Not Available
012-082 Eject Motor REVERSE ON/OFF - Same as Name X X Not Available
012-083 Eject Clamp Low DOWN - Same as Name X X Not Available
012-084 Eject Clamp Middle DOWN - Same as Name X X Not Available
012-085 Eject Clamp UP - Same as Name X X Not Available
012-086 Set Clamp Paddle Solenoid ON L Same as Name X X Not Available
013-022 Knife Motor Forward ON/OFF H = ON Same as Name X X
013-023 Knife Motor Reverse ON/OFF H = ON Same as Name X X
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
