6-129
WorkCentre 5225, 5230
Component Control
General Procedures
Launch Version
013-024 Front Booklet Staple Motor Forward ON/
OFF
H = ON Same as Name X X
013-025 Front Booklet Staple Motor Reverse ON/
OFF
H = ON Same as Name X X
013-026 Rear Booklet Staple Motor Forward ON/
OFF
H = ON Same as Name X X
013-027 Rear Booklet Staple Motor Reverse ON/
OFF
H = ON Same as Name X X
013-028 Booklet Staple Move Motor IN Pulse ON Booklet Stapler moves to the IN side X X 350 pulses
013-029 Booklet Staple Move Motor OUT Pulse ON Booklet Stapler moves to the OUT
side
X X 350 pulses
042-001 MAIN MOTOR ON L Same as Name X X Not Available
042-002 FUSER FAN MOTOR (HIGH SPEED) - Fuser Fan changes from Low to High
Rotation.
X X Not Available
042-003 ROS FAN MOTOR ON L ROS Fan Motor Start & Stop X X Not Available
047-001 OFFSET MOTOR1 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-002 FUSER FAN MOTOR(HIGH SPEED) - Fuser Fan changes from Low to High
Rotation.
X X Not Available
047-003 OFFSET MOTOR2 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-004 OFFSET MOTOR2 REVERSE ROTA-
TION
- Same as Name X X EXIT
047-005 OFFSET MOTOR1 REVERSE ROTA-
TION
- Same as Name X X EXIT
047-006 MAIN MOTOR L Same as Name X X Not Available
047-022 EXIT DRIVE MOTOR FORWARD(Eject
Paper out)
- Same as Name X X Not Available
047-023 EXIT DRIVE MOTOR REVERSE(send
paper into Dup)
- Same as Name X X Not Available
047-024 EXIT GATE SOLENOID H Switch Gate to Exit2/FUT X X Not Available
047-025 FACE UP GATE SOLENOID L Switch FUT Gate to Face Up Tray X X EXIT
047-026 EXIT 2 FAN - Exit 2 FAN rotating X X Not Available
061-001 ROS MOTOR ON L ROS Motor Start & Stop X X Not Available
071-001 TRAY1 LIFTER UP(FEED MOTOR
Reverse)
- Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X Not Available
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
