February, 2008
6-130
WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
071-002 TRAY2 LIFTER UP(FEED MOTOR
Reverse)
- Turn Lift Up Motor on for two sec-
onds when Tray 2 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 2 Level Sensor is
''H''(lifted up).
O X Not Available
071-003 TRAY3 LIFTER UP(FEED MOTOR
Reverse)
- Turn Lift Up Motor on for two sec-
onds when Tray 3 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 3 Level Sensor is
''H''(lifted up).
O X Not Available
071-004 TRAY4 LIFTER UP(FEED MOTOR
Reverse)
- Turn Lift Up Motor on for two sec-
onds when Tray 4 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 4 Level Sensor is
''H''(lifted up).
O X Not Available
071-007 TRAY1 FEED MOTOR - Same as Name X X Not Available
071-008 TRAY2 FEED MOTOR - Same as Name X X Not Available
071-012 SMH FEED CLUTCH L Same as Name X X Not Available
071-036 MAIN MOTOR ON L Same as Name X X Not Available
071-037 DRUM MOTOR ON L Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
073-006 T/A MOTOR L Same as Name X X Not Available
073-009 TRAY3 FEED MOTOR - Same as Name X X Not Available
073-010 TRAY4 FEED MOTOR - Same as Name X X Not Available
073-013 TM T/A CL L Same as Name X X Not Available
073-016 DUP MOTOR - In high speed (> process speed) X X DM
073-018 HOT-LINE CHECK with alternative signal - Hot-Line Control MCU toggles
FEED-STOP signal alternatively in
period of 400-600ms, Tray Module
toggles FEED-READY signal in
period of 1900-2100ms.
O X Not Available
073-019 TRAY3 FEED MOTOR(Hot-Line) L Hot-Line Control X X Not Available
073-020 TRAY4 FEED MOTOR(Hot-Line) L Hot-Line Control X X Not Available
073-026 DUP MOTOR Rotate for sending paper
out to regi
- In low speed (=process speed) X X DM
089-002 REGI CLUTCH L Same as Name X X Not Available
091-002 BCR AC BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
