February, 2008
7-17
WorkCentre 5225, 5230
Plug/Jack Locations
Wiring Data
Launch Version
Plug/Jack Locations
How to use the Plug/Jack Location List
The Plug/Jack Location List below is provided to locate plugs, jacks, or other terminating
devices. Locate the desired termination device in the first column (Connector Number) of the
list. Refer to the second column (Figure Number) to determine the figure number of the electri
-
cal termination device. Refer to the (Item Number) column to determine the item number in the
adjacent Figure Number column. The fourth column supplies the title of the Figure.
NOTE: Connectors numbered “CN” and “FS” are listed after the “P and J” connectors.
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number
Figure Title
P/J1 Figure 1 8 Control Panel
P/J1 Figure 16 17 LVPS, Main Switch
P/J2 Figure 16 11 LVPS, Main Switch
P/J3 Figure 16 14 LVPS, Main Switch
P/J4 Figure 16 19 LVPS, Main Switch
P/J6 Figure 16 12 LVPS, Main Switch
P/J7 Figure 16 13 LVPS, Main Switch
P/J11 Figure 16 16 LVPS, Main Switch
P/J12 Figure 16 15 LVPS, Main Switch
P/J50 Figure 15 5 Power Unit
P/J56 Figure 16 4 LVPS, Main Switch
P/J57 Figure 16 1 LVPS, Main Switch
P/J68 Figure 16 3 LVPS, Main Switch
P/J69 Figure 16 2 LVPS, Main Switch
P/J72 Figure 15 3 Power Unit
P/J73 Figure 15 2 Power Unit
P/J74 Figure 15 1 Power Unit
P/J75 Figure 15 4 Power Unit
P/J100 Figure 9 2 L/H Lower, Tray1/2 Feeder
P/J101 Figure 9 3 L/H Lower, Tray1/2 Feeder
P/J101A Figure 17 2 Tray3/4 Feeder (2TM)
P/J101A Figure 19 2 Tray3/4 Feeder (TTM)
P/J101B Figure 17 2 Tray3/4 Feeder (2TM)
P/J101B Figure 19 2 Tray3/4 Feeder (TTM)
P/J102 Figure 9 2 L/H Lower, Tray1/2 Feeder
P/J102A Figure 17 3 Tray3/4 Feeder (2TM)
P/J102A Figure 19 3 Tray3/4 Feeder (TTM)
P/J102B Figure 17 3 Tray3/4 Feeder (2TM)
P/J102B Figure 19 3 Tray3/4 Feeder (TTM)
P/J103 Figure 9 3 L/H Lower, Tray1/2 Feeder
P/J104 Figure 8 3 Regi. Sensor, Regi. Clutch
P/J105 Figure 9 4 L/H Lower, Tray1/2 Feeder
P/J106 Figure 9 7 L/H Lower, Tray1/2 Feeder
P/J107 Figure 7 9 Duplex Unit, MPT
P/J108 Figure 7 10 Duplex Unit, MPT
P/J109 Figure 13 11 IOT Rear Location
P/J110 Figure 13 12 IOT Rear Location
P/J111 Figure 5 8 Exit2
P/J112 Figure 5 6 Exit2
P/J116 Figure 5 2 Exit2
P/J117 Figure 6 1 No.1 OCT, Fuser Assembly
P/J120 Figure 13 4 IOT Rear Location
P/J121 Figure 16 18 LVPS, Main Switch
P/J123 Figure 7 2 Duplex Unit, MPT
P/J124 Figure 7 1 Duplex Unit, MPT
P/J125 Figure 3 1 HVPS, Dispens Motor, Fuser Exit Sensor
P/J126 Figure 4 1 ROS Unit, Exit PWB
P/J127 Figure 3 2 HVPS, Dispens Motor, Fuser Exit Sensor
P/J130 Figure 4 8 ROS Unit, Exit PWB
P/J131 Figure 6 3 No.1 OCT, Fuser Assembly
P/J132 Figure 6 4 No.1 OCT, Fuser Assembly
P/J140 Figure 4 10 ROS Unit, Exit PWB
P/J150 Figure 8 2 Regi. Sensor, Regi. Clutch
P/J160 Figure 4 12 ROS Unit, Exit PWB
P/J170 Figure 4 13 ROS Unit, Exit PWB
P/J201 Figure 4 11 ROS Unit, Exit PWB
P/J201 Figure 9 1 L/H Lower, Tray1/2 Feeder
P/J202 Figure 9 1 L/H Lower, Tray1/2 Feeder
P/J204 Figure 13 9 IOT Rear Location
P/J205 Figure 7 7 Duplex Unit, MPT
P/J206 Figure 13 1 IOT Rear Location
P/J207 Figure 5 4 Exit2
P/J208 Figure 5 5 Exit2
P/J209 Figure 5 7 Exit2
P/J210 Figure 5 3 Exit2
P/J212 Figure 7 6 Duplex Unit, MPT
P/J214 Figure 13 7 IOT Rear Location
P/J215 Figure 8 1 Regi. Sensor, Regi. Clutch
P/J216 Figure 3 3 HVPS, Dispens Motor, Fuser Exit Sensor
P/J219 Figure 3 4 HVPS, Dispens Motor, Fuser Exit Sensor
P/J220 Figure 5 1 Exit 2
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
To Next Page
