WorkCentre 5225, 5230
Plug/Jack Locations
Launch Version
Wiring Data
P/J220A Figure 17 1 Tray3/4 Feeder (2TM)
P/J102B Figure 19 1 Tray3/4 Feeder (TTM)
P/J220B Figure 17 1 Tray3/4 Feeder (2TM)
P/J102B Figure 19 1 Tray3/4 Feeder (TTM)
P/J300 Figure 10 1 ESS 1 of 2
P/J301 Figure 10 2 ESS 1 of 2
P/J302 Figure 10 7 ESS 1 of 2
P/J320 Figure 11 4 ESS 2 of 2
P/J330 Figure 11 7 ESS 2 of 2
P/J332 Figure 11 5 ESS 2 of 2
P/J333 Figure 11 6 ESS 2 of 2
P/J340 Figure 10 10 ESS 1 of 2
P/J341 Figure 10 9 ESS 1 of 2
P/J342 Figure 10 8 ESS 1 of 2
P/J343 Figure 10 3 ESS 1 of 2
P/J351 Figure 10 11 ESS 1 of 2
P/J380 Figure 10 12 ESS 1 of 2
P/J387 Figure 10 4 ESS 1 of 2
P/J388 Figure 11 1 ESS 2 of 2
P/J389 Figure 10 5 ESS 1 of 2
P/J390 Figure 11 2 ESS 2 of 2
P/J392 Figure 11 3 ESS 2 of 2
P/J400 Figure 14 20 MCU PWB
P/J401 Figure 14 21 MCU PWB
P/J402 Figure 14 3 MCU PWB
P/J403 Figure 14 6 MCU PWB
P/J404 Figure 14 4 MCU PWB
P/J405 Figure 14 8 MCU PWB
P/J406 Figure 14 2 MCU PWB
P/J407 Figure 14 1 MCU PWB
P/J408 Figure 14 7 MCU PWB
P/J409 Figure 14 10 MCU PWB
P/J410 Figure 14 9 MCU PWB
P/J411 Figure 14 11 MCU PWB
P/J412 Figure 14 22 MCU PWB
P/J413 Figure 14 16 MCU PWB
P/J414 Figure 14 14 MCU PWB
P/J415 Figure 14 13 MCU PWB
P/J416 Figure 14 19 MCU PWB
P/J417 Figure 14 15 MCU PWB
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
P/J419 Figure 14 12 MCU PWB
P/J420 Figure 14 24 MCU PWB
P/J421 Figure 14 23 MCU PWB
P/J423 Figure 14 5 MCU PWB
P/J425 Figure 14 18 MCU PWB
P/J429 Figure 14 17 MCU PWB
P/J430 Figure 4 4 ROS Unit, Exit PWB
P/J431 Figure 4 3 ROS Unit, Exit PWB
P/J432 Figure 4 5 ROS Unit, Exit PWB
P/J433 Figure 4 7 ROS Unit, Exit PWB
P/J434 Figure 4 6 ROS Unit, Exit PWB
P/J500 Figure 3 5 HVPS, Dispens Motor, Fuser Exit Sensor
P/J521 Figure 16 8 LVPS, Main Switch
P/J522 Figure 16 7 LVPS, Main Switch
P/J523 Figure 16 10 LVPS, Main Switch
P/J524 Figure 16 9 LVPS, Main Switch
P/J526 Figure 16 5 LVPS, Main Switch
P/J527 Figure 16 6 LVPS, Main Switch
P/J540 Figure 7 3 Duplex Unit, MPT
P/J541 Figure 7 4 Duplex Unit, MPT
P/J541 Figure 18 2 2TM Rear Location
P/J541 Figure 20 1 TTM Rear Location
P/J542 Figure 7 5 Duplex Unit, MPT
P/J548 Figure 18 1 2TM Rear Location
P/J548 Figure 20 11 TTM Rear Location
P/J549 Figure 18 7 2TM Rear Location
P/J549 Figure 20 10 TTM Rear Location
P/J552 Figure 18 8 2TM Rear Location
P/J552 Figure 20 9 TTM Rear Location
P/J554 Figure 18 3 2TM Rear Location
P/J554 Figure 20 2 TTM Rear Location
P600 Figure 6 2 No.1 OCT, Fuser Assembly
J600 Figure 13 5 IOT Rear Location
P/J601 Figure 9 8 L/H Lower, Tray1/2 Feeder
P/J602 Figure 9 6 L/H Lower, Tray1/2 Feeder
P/J605 Figure 13 8 IOT Rear Location
P606 Figure 5 10 Exit 2
J606 Figure 13 3 IOT Rear Location
P/J607 Figure 13 10 IOT Rear Location
P/J608 Figure 9 5 L/H Lower, Tray1/2 Feeder
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
To Next Page
