FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
28
management port
3
VGA port
-
-
⚫
12 x 2.5" drive configuration (4 x SAS/SATA + 8 x NVMe)
Figure 5-14 Ports on the front panel
1
USB 3.0 port
2
iBMC direct connect
management port
3
VGA port
-
-
⚫
12 x 3.5" drive configuration
Figure 5-15 Ports on the front panel
1
USB 3.0 port
2
iBMC direct connect
management port
3
VGA port
-
-
⚫
20 x 2.5" drive configuration (4 x SAS/SATA + 16 x NVMe)
Figure 5-16 Ports on the front panel
