FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
32
1
Slot2
2
Slot3
3
Slot6
4
Slot7
5
PSU 2
6
Power supply unit (PSU) 1
7
(Optional) FlexIO card 2
NOTE
The FlexIO card slot supports
only OCP 3.0 network adapters.
8
(Optional) Slot 9
9
(Optional) FlexIO card 1
NOTE
The FlexIO card slot supports
only OCP 3.0 network adapters.
-
-
⚫
For details about the OCP 3.0 network adapter, see 5.1.6.1 OCP 3.0 Network Adapters .
⚫
The figure is for reference only. The actual configuration may vary.
⚫
Server with 11 Standard PCIe Cards on the Rear Panel
1
Slot1
2
Slot2
3
Slot3
4
Slot4
5
Slot5
6
Slot6
7
Slot7
8
Slot8
9
Slot9
10
Slot10
11
Slot11
12
Power supply 2
13
Power supply unit (PSU) 1
14
(Optional) FlexIO card 2
NOTE
The FlexIO card slot supports
only OCP 3.0 network adapters.
15
(Optional) FlexIO card 1
NOTE
The FlexIO card slot supports
only OCP 3.0 network adapters.
-
-
