Xilinx KC705 User Manual

KC705 Evaluation Board 65
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
C2 FMC_HPC_DP0_C2M_P D2 D1 PWRCTL1_VCC4A_PG
C3 FMC_HPC_DP0_C2M_N D1 D4 FMC_HPC_GBTCLK0_M2C_P LVDS C8
C6 FMC_HPC_DP0_M2C_P E4 D5 FMC_HPC_GBTCLK0_M2C_N LVDS C7
C7 FMC_HPC_DP0_M2C_N E3 D8 FMC_HPC_LA01_CC_P LVDS D26
C10 FMC_HPC_LA06_P LVDS H30 D9 FMC_HPC_LA01_CC_N LVDS C26
C11 FMC_HPC_LA06_N LVDS G30 D11 FMC_HPC_LA05_P LVDS G29
C14 FMC_HPC_LA10_P LVDS D29 D12 FMC_HPC_LA05_N LVDS F30
C15 FMC_HPC_LA10_N LVDS C30 D14 FMC_HPC_LA09_P LVDS B30
C18 FMC_HPC_LA14_P LVDS B28 D15 FMC_HPC_LA09_N LVDS A30
C19 FMC_HPC_LA14_N LVDS A28 D17 FMC_HPC_LA13_P LVDS A25
C22 FMC_HPC_LA18_CC_P LVDS F21 D18 FMC_HPC_LA13_N LVDS A26
C23 FMC_HPC_LA18_CC_N LVDS E21 D20 FMC_HPC_LA17_CC_P LVDS F20
C26 FMC_HPC_LA27_P LVDS C19 D21 FMC_HPC_LA17_CC_N LVDS E20
C27 FMC_HPC_LA27_N LVDS B19 D23 FMC_HPC_LA23_P LVDS B22
C30 FMC_HPC_IIC_SCL D24 FMC_HPC_LA23_N LVDS A22
C31 FMC_HPC_IIC_SDA D26 FMC_HPC_LA26_P LVDS B18
C34 GA0=0=GND D27 FMC_HPC_LA26_N LVDS A18
C35 VCC12_P D29 FMC_HPC_TCK_BUF
C37 VCC12_P D30 FMC_TDI_BUF
C39 VCC3V3 D31 FMC_HPC_TDO_LPC_TDI
D32 VCC3V3
D33 FMC_TMS_BUF
D34 NC
D35 GA1=0=GND
D36 VCC3V3
D38 VCC3V3
D40 VCC3V3
E2 FMC_HPC_HA01_CC_P LVDS H14 F1 FMC_HPC_PG_M2C LVDS J29
E3 FMC_HPC_HA01_CC_N LVDS G14 F4 FMC_HPC_HA00_CC_P LVDS D12
E6 FMC_HPC_HA05_P LVDS F15 F5 FMC_HPC_HA00_CC_N LVDS D13
E7 FMC_HPC_HA05_N LVDS E16 F7 FMC_HPC_HA04_P LVDS F11
Table 1-28: HPC Connections, J22 to FPGA U1 (Cont’d)
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
Send Feedback
