KC705 Evaluation Board 66
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
E9 FMC_HPC_HA09_P LVDS F12 F8 FMC_HPC_HA04_N LVDS E11
E10 FMC_HPC_HA09_N LVDS E13 F10 FMC_HPC_HA08_P LVDS E14
E12 FMC_HPC_HA13_P LVDS L16 F11 FMC_HPC_HA08_N LVDS E15
E13 FMC_HPC_HA13_N LVDS K16 F13 FMC_HPC_HA12_P LVDS C15
E15 FMC_HPC_HA16_P LVDS L15 F14 FMC_HPC_HA12_N LVDS B15
E16 FMC_HPC_HA16_N LVDS K15 F16 FMC_HPC_HA15_P LVDS H15
E18 FMC_HPC_HA20_P LVDS K13 F17 FMC_HPC_HA15_N LVDS G15
E19 FMC_HPC_HA20_N LVDS J13 F19 FMC_HPC_HA19_P LVDS H11
E21 NC F20 FMC_HPC_HA19_N LVDS H12
E22 NC F22 NC
E24 NC F23 NC
E25 NC F25 NC
E27 NC F26 NC
E28 NC F28 NC
E30 NC F29 NC
E31 NC F31 NC
E33 NC F32 NC
E34 NC F34 NC
E36 NC F35 NC
E37 NC F37 NC
E39 VADJ F38 NC
F40 VADJ
G2 FMC_HPC_CLK1_M2C_P LVDS D17 H1 NC
G3 FMC_HPC_CLK1_M2C_N LVDS D18 H2 FMC_HPC_PRSNT_M2C_B LVCMOS
25
M20
G6 FMC_HPC_LA00_CC_P LVDS C25 H4 FMC_HPC_CLK0_M2C_P LVDS D27
G7 FMC_HPC_LA00_CC_N LVDS B25 H5 FMC_HPC_CLK0_M2C_N LVDS C27
G9 FMC_HPC_LA03_P LVDS H26 H7 FMC_HPC_LA02_P LVDS H24
G10 FMC_HPC_LA03_N LVDS H27 H8 FMC_HPC_LA02_N LVDS H25
G12 FMC_HPC_LA08_P LVDS E29 H10 FMC_HPC_LA04_P LVDS G28
G13 FMC_HPC_LA08_N LVDS E30 H11 FMC_HPC_LA04_N LVDS F28
Table 1-28: HPC Connections, J22 to FPGA U1 (Cont’d)
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
