Xilinx KC705 User Manual

KC705 Evaluation Board 67
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
G15 FMC_HPC_LA12_P LVDS C29 H13 FMC_HPC_LA07_P LVDS E28
G16 FMC_HPC_LA12_N LVDS B29 H14 FMC_HPC_LA07_N LVDS D28
G18 FMC_HPC_LA16_P LVDS B27 H16 FMC_HPC_LA11_P LVDS G27
G19 FMC_HPC_LA16_N LVDS A27 H17 FMC_HPC_LA11_N LVDS F27
G21 FMC_HPC_LA20_P LVDS E19 H19 FMC_HPC_LA15_P LVDS C24
G22 FMC_HPC_LA20_N LVDS D19 H20 FMC_HPC_LA15_N LVDS B24
G24 FMC_HPC_LA22_P LVDS C20 H22 FMC_HPC_LA19_P LVDS G18
G25 FMC_HPC_LA22_N LVDS B20 H23 FMC_HPC_LA19_N LVDS F18
G27 FMC_HPC_LA25_P LVDS G17 H25 FMC_HPC_LA21_P LVDS A20
G28 FMC_HPC_LA25_N LVDS F17 H26 FMC_HPC_LA21_N LVDS A21
G30 FMC_HPC_LA29_P LVDS C17 H28 FMC_HPC_LA24_P LVDS A16
G31 FMC_HPC_LA29_N LVDS B17 H29 FMC_HPC_LA24_N LVDS A17
G33 FMC_HPC_LA31_P LVDS G22 H31 FMC_HPC_LA28_P LVDS D16
G34 FMC_HPC_LA31_N LVDS F22 H32 FMC_HPC_LA28_N LVDS C16
G36 FMC_HPC_LA33_P LVDS H21 H34 FMC_HPC_LA30_P LVDS D22
G37 FMC_HPC_LA33_N LVDS H22 H35 FMC_HPC_LA30_N LVDS C22
G39 VADJ H37 FMC_HPC_LA32_P LVDS D21
H38 FMC_HPC_LA32_N LVDS C21
H40 VADJ
J2 NC K1 NC
J3 NC K4 NC
J6 FMC_HPC_HA03_P LVDS C12 K5 NC
J7 FMC_HPC_HA03_N LVDS B12 K7 FMC_HPC_HA02_P LVDS D11
J9 FMC_HPC_HA07_P LVDS B14 K8 FMC_HPC_HA02_N LVDS C11
J10 FMC_HPC_HA07_N LVDS A15 K10 FMC_HPC_HA06_P LVDS D14
J12 FMC_HPC_HA11_P LVDS B13 K11 FMC_HPC_HA06_N LVDS C14
J13 FMC_HPC_HA11_N LVDS A13 K13 FMC_HPC_HA10_P LVDS A11
J15 FMC_HPC_HA14_P LVDS J16 K14 FMC_HPC_HA10_N LVDS A12
J16 FMC_HPC_HA14_N LVDS H16 K16 FMC_HPC_HA17_CC_P LVDS G13
J18 FMC_HPC_HA18_P LVDS K14 K17 FMC_HPC_HA17_CC_N LVDS F13
J19 FMC_HPC_HA18_N LVDS J14 K19 FMC_HPC_HA21_P LVDS J11
Table 1-28: HPC Connections, J22 to FPGA U1 (Cont’d)
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
J22 Pin Schematic Net Name
I/O
Standard
FPGA
U1 Pin
Send Feedback
