Chapter 1: KC705 Evaluation Board Features
• GTX transceivers
°
FMC HPC connector (four GTX transceivers)
°
FMC LPC connector (one GTX transceiver)
°
SMA connectors (one pair each for TX, RX, and REFCLK)
°
PCI Express (eight lanes)
°
Small form-factor pluggable plus (SFP+) connector
°
Ethernet PHY SGMII interface (RJ-45 connector)
• PCI Express endpoint connectivity
°
Gen1 8-lane (x8)
°
Gen2 8-lane (x8)
• SFP+ Connector
• 10/100/1000 tri-speed Ethernet PHY
• USB-to-UART bridge
• High-Definition Multimedia Interface ™ (HDMI) technology codec
•I2C bus
°
I2C mux
°
I2C EEPROM (1 KB)
°
USER I2C programmable LVDS oscillator
°
DDR3 SODIMM socket
°
HDMI codec
°
FMC HPC connector
°
FMC LPC connector
°
SFP+ connector
°
I2C programmable jitter-attenuating precision clock multiplier
•Status LEDs
°
Ethernet status
°
Power good
°
FPGA INIT
°
FPGA DONE
•User I/O
°
USER LEDs (eight GPIO)
