KC705 Evaluation Board 8
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
°
User pushbuttons (five directional)
°
CPU reset pushbutton
°
User DIP switch (4-pole GPIO)
°
User edge drive rotary encoder switch
°
User SMA GPIO connectors (one pair)
°
LCD character display (16 characters x 2 lines)
•Switches
°
Power on/off slide switch
°
FPGA_PROG_B pushbutton switch
• VITA 57.1 FMC HPC Connector
• VITA 57.1 FMC LPC Connector
• Power management
°
PMBus voltage and current monitoring via TI power controller
• XADC header
• Configuration options
°
Linear BPI flash memory
°
Quad SPI flash memory
°
USB JTAG configuration port
°
Platform cable header JTAG configuration port
The KC705 board block diagram is shown in Figure 1-1. The KC705 board schematics are
available for download from the Kintex-7 FPGA KC705 Evaluation Kit website.
CAUTION! The KC705 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
prevention measures when handling the board.
