Detailed Description
R
have the IIC pull-up resistors present on the expansion card. Bidirectional level shifting
transistors allow the expansion card to utilize 2.5V to 5V signaling on the IIC bus.
Power supply connections to the expansion connectors provide ground, 2.5V, 3.3V, and 5V
power pins. If the expansion card draws significant power from the ML50x board, ensure
that the total power draw can be supplied by the board.
The ML50x expansion connector is backward compatible with the expansion connectors
on the ML40x, ML32x, and ML42x boards, thereby allowing their daughter cards to be
used with the ML50x Evaluation Platform. Table 1-11 summarizes the additional
expansion I/O connections.
Table 1-11: Additional Expansion I/O Connections (J5)
J5 Pin Label FPGA Pin Description
1
VCC5
–
5V Power Supply
2
VCC5
–
5V Power Supply
3
VCC5
–
5V Power Supply
4
VCC5
–
5V Power Supply
5
NC
–
Not Connected
6
VCC3V3
–
3.3V Power Supply
7
VCC3V3
–
3.3V Power Supply
8
VCC3V3
–
3.3V Power Supply
9
VCC3V3
–
3.3V Power Supply
10
NC
–
Not Connected
11
FPGA_EXP_TMS
–
Expansion TMS
12
FPGA_EXP_TCK
–
Expansion TCK
13
FPGA_EXP_TDO
–
Expansion TDO
14
FPGA_EXP_TDI
–
Expansion TDI
15 GPIO_LED_N
AF13
LED North
16 SW3 (N)
U8
GPIO Switch North
17 GPIO_LED_C
E8
LED Center
18 SW14 (C)
AJ6
GPIO Switch Center
19 GPIO_LED_W
AF23
LED West
20 SW13 (W)
AJ7
GPIO Switch West
21 GPIO_LED_S
AG12
LED South
22 SW11 (S)
V8
GPIO Switch South
23 GPIO_LED_E
AG23
LED East
24 SW12 (E)
AK7
GPIO Switch East
25 GPIOLED 0
H18
GPIO LED 0
