Chapter 1: ML505/ML506/ML507 Evaluation Platform
R
Other Expansion I/O Connectors
In addition to the high-speed I/O paths, additional I/O signals and power connections are
available to support expansion cards plugged into the ML50x board. Fourteen I/O pins
from the general-purpose pushbutton switches and LEDs on the board are connected to
expansion connector J5. This permits additional I/Os to connect to the expansion
connector if the pushbutton switches and LEDs are not used. The connection also allows
the expansion card to utilize the pushbutton switches and LEDs on the board.
The expansion connector also allows the board's JTAG chain to be extended onto the
expansion card by setting jumper J21 accordingly.
The IIC bus on the board is also extended onto the expansion connector to allow additional
IIC devices to be bused together. If the expansion IIC bus is to be utilized, the user must
18 HDR1_18 L33
20 HDR1_20 M32
22 HDR1_22 P34
24 HDR1_24 N34
26 HDR1_26 AA34
28 HDR1_28 AD32
30 HDR1_30 Y34
32 HDR1_32 Y32
34 HDR1_34 W32
36 HDR1_36 AH34
38 HDR1_38 AE32
40 HDR1_40 AG32
42 HDR1_42 AH32
44 HDR1_44 AK34
46 HDR1_46 AK33
48 HDR1_48 AJ32
50 HDR1_50 AK32
52 HDR1_52 AL34
54 HDR1_54 AL33
56 HDR1_56 AM33
58 HDR1_58 AJ34
60 HDR1_60 AM32
62 HDR1_62 AN34
64 HDR1_64 AN33
Table 1-10: Expansion I/O Single-Ended Connections (J6) (Cont’d)
J6 Pin Schematic Net Name FPGA Pin
