Appendix A
Board Revisions
This appendix describes the major differences in the ML50x platforms (Table A-1).
Table A-1: ML50x Platform Details
Platform Device Package PCB Product Revision Description
ML505
XC5VLX50T-1C 1FFG1136 Rev A 0483688-03 and up
ML505 is an LXT platform
that supports RocketIO GTP
transceivers
.
(1)
XC5VLX50T-1CES 1FFG1136 Rev A
0483688-01
0483688-02
ML506
XC5VSX50T-1C 1FFG1136 Rev A 0483729-03 and up
ML506 is an SXT platform
that supports RocketIO GTP
transceivers
.
(1)
XC5VSX50T-1CES 1FFG1136 Rev A
0483729-01
0483729-02
ML507 XC5VFX70T-1CES
1FFG1136 Rev A 0483906-01 and up
ML507 is an FXT platform
that supports RocketIO GTX
transceivers
.
(2)
Notes:
1. Where AVCC_PLL voltage is set to 1.2V. (R176 = 2.43K 1%; R177 = 4.99K 1%)
2. Where AVCC_PLL voltage is set to 1.0V. (R176 = 1.13K 1%; R177 = 4.53K 1%)
