Xilinx RocketIO User Manual

132 www.xilinx.com RocketIO™ Transceiver User Guide
UG024 (v3.0) February 22, 2007
Appendix A: RocketIO Transceiver Timing Model
R
T
GCCK
_TRST/T
GCKC
_TRST Control inputs TXRESET
T
GCCK
_TKCH/T
GCKC
_TKCH Control inputs TXCHARISK[3:0]
T
GCCK
_TCDM/T
GCKC
_TCDM Control inputs TXCHARDISPMODE[3:0]
T
GCCK
_TCDV/T
GCKC
_TCDV Control inputs TXCHARDISPVAL[3:0]
T
GDCK
_CFGIN/T
GCKD
_CFGIN Data inputs CONFIGIN
T
GDCK
_TDAT/T
GCKD
_TDAT Data inputs TXDATA[31:0]
Clock to Out:
T
GCKST
_TBERR Status outputs TXBUFERR
T
GCKST
_TKERR Status outputs TXKERR[3:0]
T
GCKDO
_TRDIS Data outputs TXRUNDISP[3:0]
T
GCKDO
_CFGOUT Data outputs CONFIGOUT
Clock:
T
TX2PWH
Clock pulse width, High state TXUSRCLK2
T
TX2PWH
Clock pulse width, Low state TXUSRCLK2
Table A-4: Parameters Relative to the TX User Clock2 (TXUSRCLK2) (Continued)
Parameter Function Signals
Table A-5: Miscellaneous Clock Parameters
Parameter Function Signals
Clock:
T
REFPWH
Clock pulse width, High state REFCLK
(1)
T
REFPWL
Clock pulse width, Low state REFCLK
(1)
T
BREFPWH
Clock pulse width, High state BREFCLK
(2)
T
BREFPWL
Clock pulse width, Low state BREFCLK
(2)
T
TX2PWH
Clock pulse width, High state TXUSRCLK
(3)
T
TX2PWL
Clock pulse width, Low state TXUSRCLK
(3)
Notes:
1. REFCLK is not synchronous to any RocketIO signals.
2. BREFCLK is not synchronous to any RocketIO signals.
3. TXUSRCLK is not synchronous to any RocketIO signals.
