Modifiable Primitives
R
CLK_COR_KEEP_IDLE FALSE
(1)
FALSE
(1)
FALSE
(1)
CLK_COR_REPEAT_WAIT 2
(1)
1
(1)
1
(1)
CLK_COR_SEQ_1_1 00110111100 00100011100 00100011100
CLK_COR_SEQ_1_2 00010010101 00000000000 00000000000
CLK_COR_SEQ_1_3 00010110101 00000000000 00000000000
CLK_COR_SEQ_1_4 00010110101 00000000000 00000000000
CLK_COR_SEQ_2_1 00000000000 00000000000 00000000000
CLK_COR_SEQ_2_2 00000000000 00000000000 00000000000
CLK_COR_SEQ_2_3 00000000000 00000000000 00000000000
CLK_COR_SEQ_2_4 00000000000 00000000000 00000000000
CLK_COR_SEQ_2_USE FALSE FALSE FALSE
CLK_COR_SEQ_LEN 4 1 1
CLK_CORRECT_USE TRUE TRUE TRUE
COMMA_10B_MASK 1111111000 1111111000 1111111000
CRC_END_OF_PKT
Note (3) Note (3)
K29_7
(1)
CRC_FORMAT FIBRE_CHAN INFINIBAND USER_MODE
(1)
CRC_START_OF_PKT
Note (3) Note (3)
K27_7
(1)
DEC_MCOMMA_DETECT TRUE TRUE TRUE
DEC_PCOMMA_DETECT TRUE TRUE TRUE
DEC_VALID_COMMA_ONLY TRUE TRUE TRUE
Lane ID(INFINBAND ONLY) NA 00000000000
(1)
NA
MCOMMA_10B_VALUE 1100000000 1100000000 1100000000
MCOMMA_DETECT TRUE TRUE TRUE
PCOMMA_10B_VALUE 0011111000 0011111000 0011111000
PCOMMA_DETECT TRUE TRUE TRUE
REF_CLK_V_SEL 000
RX_BUFFER_USE TRUE TRUE TRUE
RX_CRC_USE FALSE
(1)
FALSE
(1)
FALSE
(1)
RX_DATA_WIDTH N
(2)
N
(2)
N
(2)
Table 1-8: Default Attribute Values: GT_FIBRE_CHAN, GT_INFINIBAND,
and GT_XAUI (Continued)
Attribute
Default
GT_FIBRE_CHAN
Default
GT_INFINIBAND
Default
GT_XAUI
