Xilinx VCU118 User Manual

VCU118 Board User Guide 100
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
J22 Sections C/D Connections to FPGA U1
C2 FMCP_HSPC_DP0_C2M_P LVDS AT42
D1 VADJ_1V8_PGOOD AK35
C3 FMCP_HSPC_DP0_C2M_N LVDS A T43 D4 FMCP_HSPC_GBTCLK0_M2C_P LVDS U40.7
C6 FMCP_HSPC_DP0_M2C_P LVDS AR45 D5 FMCP_HSPC_GBTCLK0_M2C_N LVDS U40.6
C7 FMCP_HSPC_DP0_M2C_N LVDS AR46 D8 FMCP_HSPC_LA01_CC_P LVDS AL30
C10 FMCP_HSPC_LA06_P LVDS AT35 D9 FMCP_HSPC_LA01_CC_N LVDS AL31
C11 FMCP_HSPC_LA06_N LVDS AT36 D11 FMCP_HSPC_LA05_P LVDS AP38
C14 FMCP_HSPC_LA10_P LVDS AP35 D12 FMCP_HSPC_LA05_N LVDS AR38
C15 FMCP_HSPC_LA10_N LVDS AR35 D14 FMCP_HSPC_LA09_P LVDS AJ33
C18 FMCP_HSPC_LA14_P LVDS AG31 D15 FMCP_HSPC_LA09_N LVDS AK33
C19 FMCP_HSPC_LA14_N LVDS AH31 D17 FMCP_HSPC_LA13_P LVDS AJ35
C22 FMCP_HSPC_LA18_CC_P LVDS R31 D18 FMCP_HSPC_LA13_N LVDS AJ36
C23 FMCP_HSPC_LA18_CC_N LVDS P31 D20 FMCP_HSPC_LA17_CC_P LVDS R34
C26 FMCP_HSPC_LA27_P LVDS V33 D21 FMCP_HSPC_LA17_CC_N LVDS P34
C27 FMCP_HSPC_LA27_N LVDS V34 D23 FMCP_HSPC_LA23_P LVDS Y32
C30 FMCP_HSPC_IIC_SCL D24 FMCP_HSPC_LA23_N LVDS W32
C31 FMCP_HSPC_IIC_SDA D26 FMCP_HSPC_LA26_P LVDS V32
C34 GA0 GND D27 FMCP_HSPC_LA26_N LVDS U33
C35 VCC12_SW D29 FMCP_HSPC_TCK_BUF
C37 VCC12_SW D30 FPGA_TDO_FMC_TDI_BUF
C39 UTIL_3V3 D31 FMCP_HSPC_TDO_HPC1_TDI
D32 UTIL_3V3
D33 FMCP_HSPC_TMS_BUF
D34 NC
D35 GA1 GND
D36 UTIL_3V3
D38 UTIL_3V3
D40 UTIL_3V3
Table 3-32: J22 VITA 57.4 FMCP HSCP Connections (Cont’d)
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
Send Feedback
