Xilinx VCU118 User Manual

VCU118 Board User Guide 101
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
J22 Sections E/F Connections to FPGA U1
E2 FMCP_HSPC_HA01_CC_P LVDS V15
F1 FMCP_HSPC_PG_M2C AL36
E3 FMCP_HSPC_HA01_CC_N LVDS U15 F4 FMCP_HSPC_HA00_CC_P LVDS N14
E6 FMCP_HSPC_HA05_P LVDS R14 F5 FMCP_HSPC_HA00_CC_N LVDS N13
E7 FMCP_HSPC_HA05_N LVDS P14 F7 FMCP_HSPC_HA04_P LVDS Y13
E9 FMCP_HSPC_HA09_P LVDS W14 F8 FMCP_HSPC_HA04_N LVDS AA13
E10 FMCP_HSPC_HA09_N LVDS V14 F10 FMCP_HSPC_HA08_P LVDS U11
E12 FMCP_HSPC_HA13_P LVDS V13 F11 FMCP_HSPC_HA08_N LVDS T11
E13 FMCP_HSPC_HA13_N LVDS U12 F13 FMCP_HSPC_HA12_P LVDS T16
E15 FMCP_HSPC_HA16_P LVDS T14 F14 FMCP_HSPC_HA12_N LVDS T15
E16 FMCP_HSPC_HA16_N LVDS R13 F16 FMCP_HSPC_HA15_P LVDS M13
E18 FMCP_HSPC_HA20_P LVDS M15 F17 FMCP_HSPC_HA15_N LVDS M12
E19 FMCP_HSPC_HA20_N LVDS L15 F19 FMCP_HSPC_HA19_P LVDS L14
E21 NC NA NA F20 FMCP_HSPC_HA19_N LVDS L13
E22 NC NA NA F22 NC NA NA
E24 NC NA NA F23 NC NA NA
E25 NC NA NA F25 NC NA NA
E27 NC NA NA F26 NC NA NA
E28 NC NA NA F28 NC NA NA
E30 NC NA NA F29 NC NA NA
E31 NC NA NA F31 NC NA NA
E33 NC NA NA F32 NC NA NA
E34 NC NA NA F34 NC NA NA
E36 NC NA NA F35 NC NA NA
E37 NC NA NA F37 NC NA NA
E39 VADJ_1V8_FPGA F38 NC NA NA
F40 VADJ_1V8_FPGA
Table 3-32: J22 VITA 57.4 FMCP HSCP Connections (Cont’d)
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
