VCU118 Board User Guide 102
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
J22 Sections G/H Connections to FPGA U1
G2 FMCP_HSPC_CLK1_M2C_P LVDS P35
H1 FMCP_HSPC_VREF_A_M2C
G3 FMCP_HSPC_CLK1_M2C_N LVDS P36 H2 FMCP_HSPC_H_PRSNT_M2C_B LVCMOS18 AL35
G6 FMCP_HSPC_LA00_CC_P LVDS AM33 H4 FMCP_HSPC_CLK0_M2C_P LVDS AL32
G7 FMCP_HSPC_LA00_CC_N LVDS AM34 H5 FMCP_HSPC_CLK0_M2C_N LVDS AM32
G9 FMCP_HSPC_LA03_P LVDS AT39 H7 FMCP_HSPC_LA02_P LVDS AJ32
G10 FMCP_HSPC_LA03_N LVDS AT40 H8 FMCP_HSPC_LA02_N LVDS AK32
G12 FMCP_HSPC_LA08_P LVDS AK29 H10 FMCP_HSPC_LA04_P LVDS AR37
G13 FMCP_HSPC_LA08_N LVDS AK30 H11 FMCP_HSPC_LA04_N LVDS AT37
G15 FMCP_HSPC_LA12_P LVDS AH33 H13 FMCP_HSPC_LA07_P LVDS AP36
G16 FMCP_HSPC_LA12_N LVDS AH34 H14 FMCP_HSPC_LA07_N LVDS AP37
G18 FMCP_HSPC_LA16_P LVDS AG34 H16 FMCP_HSPC_LA11_P LVDS AJ30
G19 FMCP_HSPC_LA16_N LVDS AH35 H17 FMCP_HSPC_LA11_N LVDS AJ31
G21 FMCP_HSPC_LA20_P LVDS N32 H19 FMCP_HSPC_LA15_P LVDS AG32
G22 FMCP_HSPC_LA20_N LVDS M32 H20 FMCP_HSPC_LA15_N LVDS AG33
G24 FMCP_HSPC_LA22_P LVDS N34 H22 FMCP_HSPC_LA19_P LVDS N33
G25 FMCP_HSPC_LA22_N LVDS N35 H23 FMCP_HSPC_LA19_N LVDS M33
G27 FMCP_HSPC_LA25_P LVDS Y34 H25 FMCP_HSPC_LA21_P LVDS M35
G28 FMCP_HSPC_LA25_N LVDS W34 H26 FMCP_HSPC_LA21_N LVDS L35
G30 FMCP_HSPC_LA29_P LVDS U35 H28 FMCP_HSPC_LA24_P LVDS T34
G31 FMCP_HSPC_LA29_N LVDS T36 H29 FMCP_HSPC_LA24_N LVDS T35
G33 FMCP_HSPC_LA31_P LVDS P37 H31 FMCP_HSPC_LA28_P LVDS M36
G34 FMCP_HSPC_LA31_N LVDS N37 H32 FMCP_HSPC_LA28_N LVDS L36
G36 FMCP_HSPC_LA33_P LVDS L34 H34 FMCP_HSPC_LA30_P LVDS N38
G37 FMCP_HSPC_LA33_N LVDS K34 H35 FMCP_HSPC_LA30_N LVDS M38
G39 VADJ_1V8_FPGA H37 FMCP_HSPC_LA32_P LVDS L33
H38 FMCP_HSPC_LA32_N LVDS K33
H40 VADJ_1V8_FPGA
Table 3-32: J22 VITA 57.4 FMCP HSCP Connections (Cont’d)
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
