VCU118 Board User Guide 103
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
J22 Sections J/K Connections to FPGA U1
J2 NC NA NA
K1 NC NA NA
J3 NC NA NA K4 NC NA NA
J6 FMCP_HSPC_HA03_P LVDS W12 K5 NC NA NA
J7 FMCP_HSPC_HA03_N LVDS V12 K7 FMCP_HSPC_HA02_P LVDS AA12
J9 FMCP_HSPC_HA07_P LVDS AA14 K8 FMCP_HSPC_HA02_N LVDS Y12
J10 FMCP_HSPC_HA07_N LVDS Y14 K10 FMCP_HSPC_HA06_P LVDS U13
J12 FMCP_HSPC_HA11_P LVDS R12 K11 FMCP_HSPC_HA06_N LVDS T13
J13 FMCP_HSPC_HA11_N LVDS P12 K13 FMCP_HSPC_HA10_P LVDS V16
J15 FMCP_HSPC_HA14_P LVDS M11 K14 FMCP_HSPC_HA10_N LVDS U16
J16 FMCP_HSPC_HA14_N LVDS L11 K16 FMCP_HSPC_HA17_CC_P LVDS R11
J18 FMCP_HSPC_HA18_P LVDS P15 K17 FMCP_HSPC_HA17_CC_N LVDS P11
J19 FMCP_HSPC_HA18_N LVDS N15 K19 FMCP_HSPC_HA21_P LVDS K14
J21 FMCP_HSPC_HA22_P LVDS K12 K20 FMCP_HSPC_HA21_N LVDS K13
J22 FMCP_HSPC_HA22_N LVDS J12 K22 FMCP_HSPC_HA23_P LVDS K11
J24 NC NA NA K23 FMCP_HSPC_HA23_N LVDS J11
J25 NC NA NA K25 NC NA NA
J27 NC NA NA K26 NC NA NA
J28 NC NA NA K28 NC NA NA
J30 NC NA NA K29 NC NA NA
J31 NC NA NA K31 NC NA NA
J33 NC NA NA K32 NC NA NA
J34 NC NA NA K34 NC NA NA
J36 NC NA NA K35 NC NA NA
J37 NC NA NA K37 NC NA NA
J39 NC NA NA K38 NC NA NA
K40 NC NA NA
Table 3-32: J22 VITA 57.4 FMCP HSCP Connections (Cont’d)
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
J22
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
