Xilinx VCU118 User Manual

VCU118 Board User Guide 56
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-10: VCU118 FPGA U1 GTY Transceiver Bank 122 Connections
MGT
Bank
FPGA
(U1)
Pin
FPGA (U1) Pin
Name
Schematic Net Name
Connected
Pin
Connected Pin
Name
Connected
Device
GTY
Bank
122
AK42 MGTYTXP0_122 FMCP_HSPC_DP8_C2M_P B28 DP8_C2M_P
FMC+ HSPC J22
AK43 MGTYTXN0_122 FMCP_HSPC_DP8_C2M_N B29 DP8_C2M_N
AG45 MGTYRXP0_122 FMCP_HSPC_DP8_M2C_P B8 DP8_M2C_P
AG46 MGTYRXN0_122 FMCP_HSPC_DP8_M2C_N B9 DP8_M2C_N
AJ40 MGTYTXP1_122 FMCP_HSPC_DP9_C2M_P B24 DP9_C2M_P
AJ41 MGTYTXN1_122 FMCP_HSPC_DP9_C2M_N B25 DP9_C2M_N
AF43 MGTYRXP1_122 FMCP_HSPC_DP9_M2C_P B4 DP9_M2C_P
AF44 MGTYRXN1_122 FMCP_HSPC_DP9_M2C_N B5 DP9_M2C_N
AG40 MGTYTXP2_122 FMCP_HSPC_DP10_C2M_P Z24 DP10_C2M_P
AG41 MGTYTXN2_122 FMCP_HSPC_DP10_C2M_N Z25 DP10_C2M_N
AE45 MGTYRXP2_122 FMCP_HSPC_DP10_M2C_P Y10 DP10_M2C_P
AE46 MGTYRXN2_122 FMCP_HSPC_DP10_M2C_N Y11 DP10_M2C_N
AE40 MGTYTXP3_122 FMCP_HSPC_DP11_C2M_P Y26 DP11_C2M_P
AE41 MGTYTXN3_122 FMCP_HSPC_DP11_C2M_N Y27 DP11_C2M_N
AD43 MGTYRXP3_122 FMCP_HSPC_DP11_M2C_P Z12 DP11_M2C_P
AD44 MGTYRXN3_122 FMCP_HSPC_DP11_M2C_N Z13 DP11_M2C_N
AF38 MGTREFCLK0P_122 FMCP_HSPC_GBTCLK2_M2C_P L12 GBTCLK2_M2C_P
AF39 MGTREFCLK0N_122 FMCP_HSPC_GBTCLK2_M2C_N L13 GBTCLK2_M2C_N
AD38 MGTREFCLK1P_122 FMCP_HSPC_GBT1_2_P 11 Q2_P
U39 ICS855S006I
clock buffer
AD39 MGTREFCLK1N_122 FMCP_HSPC_GBT1_2_N 12 Q2_N
